Home > Products > Wellhead Tools > ZQ162-50 power tong
ZQ162-50 power tong
- 100 Set / Sets per Month
- main port of China
- T/T
Product Details
| Place of Origin: | Shandong, China | Brand Name: | API 7K | Model Number: | ZQ162-50 |
| Type: | Other | Machine Type: | Drilling Equipment | Certification: | AISI |
| Material: | High Manganese Steel | Processing Type: | Other | Use: | Well Drilling |
Product Description
Specifications
1,ZQ162-50 power tong2.Standard SY/T5074 and API 7K
3,Size from 85~162 mm
4,Max torque:50Kn.m
5,The speed high gear:60 rpm
ZQ162-50 power tong:
ZQ drill pipe power tong are designed and manufactured according to API Spe 7K"specification for drilling equipment"
The tong is a combination of spinning tong and torque tong .It substitutes cathead, suspension tong and spinning rope in making-up and breaking out.
Thechnical Specifications:
Model | ZQ203-125I | ZQ203-100 | ZQ203-100II | ZQ203-100III | ZQ162-50 | ZQ127-25 | |
Size range | mm | 127-203 | 127-203 | 127-203 | 127-203 | 85-162 | 65-127 |
in | 31/2coupling-8body | 31/2coupling-8body | 31/2coupling-8body | 31/2coupling-8body | 23/8coupling-5body | 23/8coupling-31/2body | |
Max. torque | kN.m | 125 | 100 | 100 | 100 | 50 | 25 |
ft.lbf | 92200 | 73750 | 73750 | 73750 | 36880 | 18440 | |
The speed of tong head Hi. | rpm | 40 | 40 | 40 | 40 | 60 | 65 |
The speed of tong head Lo. | rpm | 2.7 | 2.7 | 2.7 | 2.7 | 4.1 | 10.5 |
Hydraulic system pressure rating | MPa | 20 | 16.6 | 16.6 | 16.6 | 16 | 12 |
psi | 2900 | 2400 | 2400 | 2400 | 2320 | 1740 | |
Hydraulic system flow rating | L/min | 114 | 114 | 114 | 114 | 120 | 180 |
gpm | 30 | 30 | 30 | 30 | 32 | 48 | |
Stroke of shifting sylinder | mm | 1500 | 1500 | 1500 | 1000 | 1000 | |
in | 59 | 59 | 59 | 39.4 | 39.4 | ||
Moving distance of tong | mm | 0-1500 | |||||
in | 0-59 | ||||||
Lifting distance of tong | m | 0-485 | 0-800 | ||||
in | 0-19 | 0-31.5 | |||||
Overall dimensions | mm | 1720*1050*1750 | 1700*1000*1400 | 1700*1000*1400 | 1750*1650*2050 | 1570*800*1190 | 1110*790*820 |
in | 68*41*69 | 67*39*55 | 67*39*55 | 69*65*81 | 62*31*47 | 44*31*32 | |
Weight | kg | 2600 | 2400 | 2500 | 3250 | 1500 | 620 |
lb | 5730 | 5290 | 5510 | 7165 | 3310 | ||
