Vegetable oil refining machine for peanut,Vegetable oil refining equipment for peanut,Vegetable oil refining plant for peanut

Vegetable oil refining machine for peanut,Vegetable oil refining equipment for peanut,Vegetable oil refining plant for peanut

1. Product Name: Vegetable oil refining machine for peanut,Vegetable oil refining equipment for peanut,Vegetable oil refining plant for peanut

Oil and Salad Oil The unit is suitable for refining various animal and plant oils,The gross oil processed to finished

goods through alkali refining,degluing,oxygenation,decoloring and deodorization,the quality may reach Class II of

national standard(former high grade cooking oil).The equipment has many advantages such as lower

investment,faster return,compact structure and good appearance.

2. Working process of Vegetable oil refining machine for peanut,Vegetable oil refining equipment for peanut,Vegetable oil refining plant for peanut

3. Introduction of Vegetable oil refining machine for peanut,Vegetable oil refining equipment for peanut,Vegetable oil refining plant for peanut

1) The main function of decoloring process is to remove oil pigment, residual soap grain and metal ions.

2) Under negative pressure, the mechanical mixing method combined with steam mixing will improve the decoloring

effect.
3) The degummed oil firstly enters into the heater to be heated to the appropriate temperature (110°C), and then goes to the bleaching earth mixing tank.
4) The bleaching earth is delivered from the low bleaching box to the temporary tank by wind.
5) The bleaching earth is added by automatic metering and is interlockingly controlled with the oil.
6) The oil mixed with the bleaching earth overflows into the continuous decolorizer, which is stirred by non-powered steam.
7) The decolored oil enters into the two alternate leaf filters to be filtered.
8) Then the filtered oil enters the decolored oil storage tank through the security filter.
9) The decolored oil storage tank is designed as the vacuum tank with the nozzle inside, so as to prevent the

decolored oil contacting with the air and influencing its peroxide value and color reversion.

4. Parameters of Vegetable oil refining machine for peanut,Vegetable oil refining equipment for peanut,Vegetable oil refining plant for peanut

Outlook of an oil refining factory

5. The visiting of our customers:

6. The Certifications:

7. Our After-Sales Service:

Interested in our machine? Pls contact me directly!
