mini pcie wifi module
USD $7 - $12.5
/ Piece
1000 Pieces(Min.Order)
- 5000 Piece / Pieces per Month
- shenzhen
- Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | OOIOT | |
| Model Number | Oolite V1.0 |
Product Description
mini pcie wifi module
The GS-Oolite V1.0 is marketed as a "openwrt module".
The device is very similiar to the TL-WR703N TL-MR3020.
Features
- Atheros AR7240 CPU (400Mhz)
- Atheros AR9331 Chipset (integrated wireless)
- 802.11 b/g/n 150Mbps (130Mbps real)
- wireless power output 20dBm - 100mW
- 16 MB flash memory, 4M/8M selectable
- DDR2 64 MB RAM
- USB 2.0 port
General GPIO: 20 (not including TX, RX)
- Tiny form factor: 27.5 * 52MM
- USB: Usb 2 master interface, support USB hub extension
Power supply voltage: 3.3V. 0.36W
2*100M network interface. 1 wan. 1 lan
GS-Oolite power is very low, working alone, only 0.36W, very suitable for battery products, it has a 150M wireless transmission rate, up to 20 gpios. can be defined as input and output.
it's design for wifi hard disk,WiFi router, remote monitoring, remote video, Industrial control DIY and so on
...
....
