Ginyi Brand High Speed Automatic Electronic Jacquard Webbing Loom Machine

FOB Price

USD $0.1 - $0.5 / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port Xiamen Fujian China
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Type:	Jacquard Loom	Application:	Webbing, Elastic , Jacquard Belt, Bra Strap etc
Production Capacity:	1800-2800m 22 hours	Place of Origin:	Fujian, China	Brand Name:	Gin Yi
Model Number:	GNC-6/45	Dimension(LWH):	180cm115cm270cm	Weight:	1600KG
Power(W):	1.5KW	Certification:	ISO	Warranty:	one year
After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Specifications:

Ginyi Brand High Speed Automatic Electronic Jacquard Webbing Loom Machine

1. GNC 6/45

2. Belt Number: 6

3. Reed Width: 45 mm

4. Max Speed: 750-850

Ginyi Brand High Speed Automatic Electronic Jacquard Webbing Loom Machine

1. Character

Ginyi computerized jacquard needle looms adopt advanced electronic controlling jacquard, which can operate stably for years. Modules and electro controlling plate adopt separated mode, which can be easily maintained. Thanks to the our advanced computer design techniques and auto oil-feeding device, and also reasonable structure, it is easy to operate and maintain this machine even for a new hand.

2. Technical Advantages

Due to the advanced auto stop devices, reasons of abnormal breakdown can be found out from the situation mentioned above and solved directly. In this case, no operation of the machine is allowed without finding out and solving the problems. There are four stop devices as follow:

Warp yarn broken stop device: Needle loom will automatically stop once a dropper fall onto the bar due to the break of the warp yarn.
Base yarn broken stop device: Loom will stop when the base spring touching the stop bar due to the break of base yarn while weaving with base yarn. The base yarn spring and stop bar need to be operated when no base yarn is being used.
Weft yarn broken stop device: The machine will automatically stop when weft spring touching the stop pole due to the break of weft yarn.
Finished belt involved stop device: One jogging switch is set on the right side of the stop plate to avoid belts being involved into the take-off roller. The operation will be stopped when the switch broke away from the plate.

3.Specifications

Product Name	Ginyi Brand High Speed Automatic Electronic Jacquard Webbing Loom Machine
MODEL	GNC-6-45
JACQUARD NEEDLES	192/240/384
BELT NUMBERS	6
REED WIDTH(mm)	45
HEALD FRAME	8
PICK REPEAT	8-40
H.P. MOTOR	1.5
MAX.SPEED R.P.M	750-850
Price Condition	FOB Xiamen
Packaging	1set/wooden case
Delivery lead time	15-25days
Minimum order	1 set
Guarantee	1 years

More sizes of Ginyi Brand High Speed Automatic Electronic Jacquard Webbing Loom Machine

MODEL	GNC-10/30	GNC-8/45	GNC-8/30	GNC-6/55	GNC-6/45	GNC-4/65	GNC-4/80
JACQUARD NEEDLES	64/128/192/240	192/240/384	192/240	192/240/384/480	192/240/384	192/240/384/480	240/480/640
BELT NUMBERS	10	8	8	6	6	4	4
REED WIDTH	30	45	30	55	45	65	80
HEALD FRAME	8	8	8	8	8	8	8
PICK REPEAT	8-40	8-40	8-40	8-40	8-40	8-40	8-40
H.P. MOTOR	1.5	1.5	1.5	1.5	1.5	1.5	1.5
MAX.SPEED R.P.M	800-900	800-900	800-900	800-900	750-850	750-850	750-850

4. Mainly Application

Making different kinds of PP webbing, Underwear Elastic, Jacquard Belt, Bra Strap, Sofa Webbing, etc., applied to accessories of garment , seat belt, bags, luggage case, home textile and so on. The following are some products of our jacquard machine for your reference.

If you need more details from us, please feel free to contact us. Your inquiry will be highly appreciated here.
