FlintStone 15 inch digital screen indoor application open frame IR tube
- 10000 Piece / Pieces per Month
- shenzhen port
- T/T Credit Card
- FlintStone 32 inch wall mount lcd network functiom wifi open frame tft lcd monitor
- FlintStone 55 inch long life span high color gamut open frame flexible electronic board
- FlintStone 42 inch high resolution high contrast ratio open frame security digital screen
- FlintStone 15 inch full color led free stand open frame tough design TV
- FlintStone 15 inch lcd monitor for meeting use tft panel screen open frame electronic display
- FlintStone 15 inch led monitor store shelf edge mount open frame industrial cctv monitor
Product Details
Place of Origin: | Guangdong, China | Brand Name: | FlintStone | Model Number: | ID1509F-JUL418 |
Type: | TFT | Application: | Indoor | Panel Size: | 371(L)*246(W)*50(H) |
Max Resolution: | 1280*800 | Viewing Angle: | 60°/60°/50°/50° | Pixel Pitch: | 0.25875mm*0.25875mm |
Color: | 24bit | Contrast Ratio: | 500:1 | Brightness: | 450cd/㎡ |
Response Time: | 15/20MS | Input Voltage: | AC100~240V 1A(MAX) |
Product Description
FlintStone 15 inch digital screen indoor application open frame IR tube
What are the features of our open frame IR tube ?
1. Industrial-grade design, heavy-duty built for non-stop loop-playing 24/7/365
2. Rich signal input ports: HDMI / VGA / BNC / AV and more
3. Metal shielding structure, anti-radiation, anti-static, anti-magnetic, anti-interference
4. Latest fan-less design, noise-less, dust-less, no potential damage of moving mechanical parts, no potential over heating hazard
5. Open frame structure: highly flexible and customizable to embed into your furniture, store shelf, wall, or any other objects as per your needs
6. Our engineers can provide design service as per your special needs
What are the functions of our open frame IR tube ?
1. Solid open frame structure and flexible brackets for embedding
2. Adopt latest 3D digital filtering and 3D digital noise reduction technology
3. Professional industrial A+ LCD panel
4. 16.7M color, true presentation of all the details
5. High brightness, high color gamut, high contrast ratio to improve the image performance
6. 5ms response time; 60,000 hours life span
7. With both flexible push buttons and IR remote control
What are the specifications of our open frame IR tube ?
1. LCD screen
LCD size: 15 inch
Active area: 304.128mm (H) X 228.096mm (V)
Screen ratio: 4:3
Resolution: 1024 X 768
Brightness: 360cd/m2
Contrast ratio: 450:1
View angle: L / R / U / D (70° / 70° / 65° / 60°)
Pixel: 0.297mm X 0.297mm
Color: 24 bit
Vertical synchronization range: 50-75 HZ
Horizontal synchronization range: 30-80 KHZ
2. Video
Color system: PAL, SECAM, NTSC, etc.
3D comb filter: yes
3D de-interlace: yes
3. Input and output
VGA input interface: X 1 (D-Sub 15 pin female)
HDMI input interface: X 1 (19P standard HDMI interface)
AV input: X 2 (BNC interface)
AV output: X 1 (BNC interface)
Audio input: X 1 (headphone socket)
Audio output: X 1 (headphone socket)
4. OSD display (screen menu display)
Menu language: Chinese, English
5. Casing
Casing material: steel
Casing color: black
VESA pitch: 100mm X 100mm,Φ4mm
Function buttons: 7 buttons
AC cable length: 1.5 M
6. Others
Power consumption: AC100~240V 1A(MAX)
Standby power consumption: <1W
Speaker power: 2 X 8 Ω / 5 W
Body size: 395mm (L) X 260mm (W) X 35mm (H)
Net weight: 4kg
Package: neutral packaging
Accessories: power adapter, remote control, etc.
Standard bracket: L shape bracket
Application environment: indoor
Working temperature: 0℃ - 45℃
Storage temperature: -20℃ - 45℃
Working humidity: 20% - 80%
Storage humidity: 10% - 95%
open frame IR tube photos
What is the application of open frame IR tube ?
- Industrial display
- Traffic control room
- Video wall
- Corporate board room
- Exhibition center
- Video conference room
- Government bodies
- Product promotion
- Entertainment platform
- Education & training
- Military command room
- Public data
More ... ...
- Media companies
- Government
- Schools
- Banks
- Super Markets
- Hospitals
- Restaurants
- Railways stations
- Bus stops
- Airport
- Hotels
More ... ...
Our certifications
Who are we?
Southern Stars Enterprises Co Ltd has focused on the original R&D, OEM & ODM of electronic and functionality designing and manufacturing of over 100 models of HEAVY DUTY digital signage player, LCD industrial display (LCD CCTV monitor) and interactive flat panel display (ifpd) since 1996. We have been relentlessly striving to achieve excellent quality level, going to great length to tackle any tiny quality defects.
We provide most durable and stable long hour loop-playing industrial-grade products to the world market of commercial usage; we also provide heavy duty while user-friendly internet digital signage system (with CMS system) and to satisfy our customers with specialist consultancy and sincere service.
Clients & business partners
Trade terms
1. Payment methods: we accept T/T, PayPal , L/C , Western Union
2. Production lead time: 3-4 working days for sample, about 25 working days for massive order.
3. We offer 12 months quality warranty.
Product packing
Why choose us?
1. With rich experience in this field since 1996, we truly understand your need for heavy duty industrial-grade products; all our products are industrial-grade designed, heavy-duty built for non-stop loop-playing 24 / 7 / 36.5. They are durable, stable, solid and tough like a rock.
2. All our products go through 72 hours of high temperature aging test before delivery; defective rate is less than 0.1%. We are the only one manufacturer to apply this rigorous testing method.
3. We always deliver on time as we promise.
4. We are proud to be appointed supplier for many Fortune 500 companies, such as Bosch, ICI Dulux, Toys ”R” Us, Siemens, etc. We are THE specialist; let us serve you with our professional experiences and specialties.
