JAL-OV8858-E06B V2.0

OmniVision OV8858 MIPI Interface Auto Focus 8MP Camera Module

Cost-Effective 1/4-Inch 8-Megapixel Image Sensor with
Video-in-Video Support for Mainstream Mobile Devices

OmniVision's OV8858 is a 1/4-inch 8-megapixel PureCel™
image sensor for the rapidly growing mainstream
smartphone and tablet market. The compact and costeffective
OV8858 sensor delivers dramatically reduced
power consumption and best-in-class performance,
making it a highly competitive solution for the nextgeneration
of mobile devices.
Compared to OmniVision's previous-generation 1/4-inch
8-megapixel sensor, the OV8858 delivers a number of
performance enhancements, including dramatically
improved full-well capacity (FWC) and sensitivity for
enhanced high- and low-light performance. It also offers a
significant reduction in power consumption and form
factor.
The sensor also features OmniVision's Video-in-Video
(ViV™) technology, which stitches together images from
the front- and rear-cameras, applies enhancements such
as independent lens correction and color compensation,
and sends the combined image to the host ISP. In ViV
mode, users can capture a portrait scene perfectly
alongside their own face, record video while narrating for
high quality video blogging, or utilize the feature for
video conferencing. This is made possible by a special
input MIPI receiver on the OV8858 that can accept image
data from a wide range of OmniVision image sensors
designed for front-facing applications of 2-megapixel
and below, thus saving a camera port on the host ISP.
The OV8858 supports an active array of 3264 x 2448
pixels (8-megapixel) operating at 30 frames per second
(fps) for zero shutter lag, enabling high-speed
photography. The sensor is capable of recording 1080p
high definition (HD) video at 60 fps, or 720p HD video at
90 fps, each with additional pixels for electronic image
stabilization (EIS). The OV8858, when paired with
OmniVision's latest 2-megapixel sensors, can provide full
resolution ViV snapshot images at 15 fps and preview
ViV video at 30 fps.
The OV8858 fits into an 8.5 x 8.5 mm camera module with
a build height of approximately 4 mm.
