Quality hot-sale bs4568 imc tuberia fabric en china
- 5000 Ton / Tons per Month
- XINGANG CHINA
- T/T
-
Unique custom sa106c thick wall steel pipe
-
Good quality promotional galvanized 3/4" emt tube
-
Good quality customized strip steel emt pipe
-
Best quality stylish hot carbon emt galvanised steel pipe
-
2013 customized promotional carbon steel pipe 420
-
New style custom high quality emt galvanised steel pipes
Product Details
| Thickness: | 1.07, 2.11 | ||||
| Section Shape: | Round | Outer Diameter: | 0.5 - 4 inch | Place of Origin: | Hebei, China |
| Secondary Or Not: | Non-secondary | Application: | Other, Pipe used for threading | Technique: | Hot Rolled |
| Certification: | UL | Surface Treatment: | Galvanized | Special Pipe: | EMT Pipe |
| Alloy Or Not: | Non-alloy |
Product Description
Specifications
bs4568 imc tuberia fabric en chinaOD:1/2"-4"
WT:standurd or economy
PACKING:IN BUNDLES
Quality hot-sale bs4568 imc tuberia fabric en china
Details for bs4568 imc tuberia fabric en china
(1)UL Approved
(2)UL797-2000
(3)Galvanized inside and outside
(4)High corrosion resistance
EMT electrical steel pipe
1) Standard: UL 797
2) Trade Size Designator: 1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2'', 2-1/2", 3", 4".
3) All sizes are furnished in the length of 10" or according to your requirement.
The EMT pipe is formed with advanced technology and equipment. It's excellent ductility
provides easy bending,cutting and joining.
Both inside and outside surface of the conduit is galvanized.So it features high corrosion resistance and is widely used under poor condition.
Specification for bs4568 imc tuberia fabric en china
| Name | EMT pipe (ELECTRICAL METALLIC CONDUIT STEEL PIPE) |
| Standard | UL797 & ANSI C80.3, UL 797,BS 4568 ,BS EN39 ,BS 31 |
| Name | IMC (INTERMEDIATE METAL CONDUIT STEEL PIPE) |
| Standard | Standard: UL1242/ANSI C80.6. BS 4568 ,BS EN39 ,BS 31 Thread: NPT |
| Size | 1/2" to 4" |
| Length | 3050mm (10 feet)or according to customer's requirement |
| Usage | Through the electrical wires with the purpose of protection for the electrical raceway system |
| Surface finished | Hot dip galvanized(HDG) for class4 and pre-galvanized (PG) for classs3 |
| Material | Carbon steel coil |
| Package | The conduits coverd with plastics then tied with steel straps |
| Delivery time | 20 to 30 days after we receive your advance payment or copy of L/C |
| Payment Term | L/C at sight or T/T |
| Wall thickness | Standard or economy |
| Package | Small package, 5 to 20 PCS/bundle, tied with wire. Master package, 5 to 20 PCS/small bundle, tied with wires, then 10 small bundles/master, tied with steel straps.each bundle covered with woven bag. |
Dimension for bs4568 imc tuberia fabric en china
| Nominal Dimension(mm) | Outside Diameter Inch(mm) | Wall Thickness Inch(mm) | Length | Estimated Weight | |||
| Inch | mm | Dimension | Tolerance | Dimension | Tolerance | (mm) | (Kg/m) |
| 1/2" | 16 | 0.706(17.93) | ±0.005(0.13) | 0.042(1.07) | 5%10% | 10(3.05) | 0.439 |
| 3/4" | 21 | 0.922(23.42) | 0.049(1.24) | 0.669 | |||
| 1 | 27 | 1.163(29.54) | 0.057(1.45) | 0.99 | |||
| 1-1-4" | 35 | 1.510(38.35) | 0.065(1.65) | 1.469 | |||
| 1-1-2" | 41 | 1.710(44.20) | 0.065(1.65) | 1.698 | |||
| 2 | 53 | 2.197(55.80) | 0.065(1.65) | 2.17 | |||
| 2-1-2" | 63 | 2.875(73.03) | ±0.010(0.25) | 0.072(1.83) | 3.177 | ||
| 3 | 78 | 3.500(88.90) | ±0.015(0.38) | 0.072(1.83) | 3.979 | ||
| 4 | 103 | 4.500(114.30) | ±0.020(0.50) | 0.083(2.11) | 5.75 |
Picture for bs4568 imc tuberia fabric en china
Workflow
Packaging&shipping for bs4568 imc tuberia fabric en china
Customer visiting
Our team
bs4568 imc tuberia fabric en china
