Customized Except 300kg 500kg Portable Lifting Hydraulic Electric Scissor Lift Platform
- 3000 Set / Sets per Month
- Tianjin /Qingdao /Shanghai
- T/T
- Hot sale !! Electric straight mast personnel lift platform man scissor
- Hydraulic Mobile Lift Small Electric Scissor Lift
- Moveable Scissor Lift Table with Competitive Price
- Electric Hydraulic Scissor Lift Table Working Platform
- Hydralic Electric Aerial Scissors lift Fixed Scissor Lift Platform Lift Table
- Hot selling crane parts,europe type crane spare parts carriage,10 20 ton overhead crane parts end carriage low price for sale
Product Details
Place of Origin: | Henan, China | Brand Name: | Xingang | Model Number: | SJG |
Lift Mechanism: | Scissor Lift | Lift Drive / Actuation: | Hydraulic | Power: | 3KW |
Rated Loading Capacity: | 300kg | Min. Lifting Height: | 0.9m | Max. Lifting Height: | 18m |
Table Size: | 1800*2000mm | Overall Dimensions: | 1200*800*1700mm---2500*1350*2300mmXinGang | Weight: | 850kg |
Certification: | ISO9001 | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
The scissor elevator lift is widely used on aerial installation & maintenance of the working sites without power supply and with smooth working grounds, such as hotels,
bus/railway stations, airports, gas station,sport stadium, large factory, grand hall, workshops,warehouse, granary, and aerial pipeline.
MODEL | LOAD CAPACITY | PLATFORM SIZE | LIFT HEIGHT | PIT DEPTH | POWER |
SJG0.3-2 | 0.3T | 1.5m x 1.5m | 2m | 400mm | 220V, 240V, 380V or 400V |
SJG0.5-3 | 0.5T | 2m x 1.8m | 3m | 500mm | 220V, 240V, 380V or 400V |
SJG1-4.5 | 1T | 2.1m x 1.5m | 4.5m | 650mm | 220V, 240V, 380V or 400V |
SJG1.5-4 | 1.5T | 2.2m x 1.6m | 4m | 600mm | 220V, 240V, 380V or 400V |
SJG2-6.5 | 2T | 5.2m x 2.8m | 6.5m | 800mm | 220V, 240V, 380V or 400V |
SJG2.5-3 | 2.5T | 5.2m x 2.6m | 3m | 750mm | 220V, 240V, 380V or 400V |
SJG2.5-3.5 | 2.5T | 5.2m x 2.6m | 3.5m | 800mm | 220V, 240V, 380V or 400V |
SJG2.5-5 | 2.5T | 5.6m x 3m | 5m | 800mm | 220V, 240V, 380V or 400V |
SJG3-2.5 | 3T | 5m x 2.3m | 2.5m | 750mm | 220V, 240V, 380V or 400V |
SJG3-3 | 3T | 5.2m x 2.6m | 3m | 800mm | 220V, 240V, 380V or 400V |
SJG3-3.5 | 3T | 5.6m x 2.7m | 3.5m | 800mm | 220V, 240V, 380V or 400V |
SJG5-10 | 5T | 4.5m x 2.5m | 10m | 1150mm | 220V, 240V, 380V or 400V |
SJG8-2.5 | 8T | 6.5m x 4.5m | 2.5m | 850mm | 220V, 240V, 380V or 400V |
SJG12-3 | 12T | 5.5m x 2.8m | 3m | 950mm | 220V, 240V, 380V or 400V |
SJG15-4.5 | 15T | 8m x 2.2m | 4.5m | 1150mm | 220V, 240V, 380V or 400V |
SJG20-5 | 20T | 6m x 3m | 5m | 1200mm | 220V, 240V, 380V or 400V |
|
Parts Showing:
Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The safety rails to guarantee safety of the goods above hydraulic lifting machine.
3) Equipped 4 guide rails, to ensure the Electric platform lift warehouse platform lift runs more smoothly and steadily.
4) The limit switch system helps the scissor elevator lift to stop at accurate position.
5) Electricity leakage protection device is equipped on, all electric components are CE certified.
6) All the Electric platform lift warehouse platform lift are passed 1.2 times loading test before leaving factory.
The workshops:
Our main products :gantry crane ,overhead crane ,portal crane,jib crane,tower crane,electric hoist ,electric winch, lift platform,electric flat carriage and lifting accessories.
Henan Xingang Crane Equipment Co., Ltd is a professional company of exporting crane .we have a good cooperation with many manufacturing crane factories ,include the experienced engineers.
We not only sale all kinds of industrial cranes,but also provide technical consultation of all sorts of crane, We have a turnkey project for the client. We control quality from raw materials to finished product,and we will send technician to guide installation after client receives goods. we have been approved ISO9000 quality management system,and has made special equipment manufacturing license .operation processing is controled under ISO9000 quality management standard.and also experienced in applying advanced digtal technology,variable-frequency regulating speed technology ,remote operation,PLC control , automation to our products .
At present ,We have exported to more countries, such as India ,Canada,Australia,Egypt ,Turky.Our exported products were highly praised from our clients.
Continuously meet the demand of customers,the best solution for customers ,improve work efficiency and improve customer satisfaction is our management principle.we would like to supply the first-class product quality ,with our excellent service to meet your demand of the crane machinery ,sincerely hopeing to growth together with you !
If you want to order our products ,Pls feel free to contact Jessie .Thanks a lot !
