professional baking oven

Specifications

1.multilayer
2.CE
3.electricity
4.stainless steel net transmission

Multi-layer drying oven

These series of roasting oven are widely used for drying all kinds of stick, piece, grain etc. Shaping inflating snack food, the user can choose different types of dryer according to layer, length or energy.



compact in frame, facilitated in operation, low occupation of space, light in weight, steady in performance, large drying area, andmore heating efficient. The belt and the heat preservation use the stainless steel. Asbestos plates are available for avoiding losing heat. A fan with 3.0KW is on the top of oven to removing moisture.

A frequency converter can adjust the drying time for the productspeed.

Variable speed of the belt is available. Electricity heating is heated by infrared heatingpipe by electricity.

There is a convenient set for spraying lubricating oil to the bearings.

For using gas or diesel oil as energy resource, we use International Brand Burner, BALTUR S.P.A.It is in good quality and safe.







Main features:



These series of roasting are widely used; it is used for all kinds of stick, piece, grain etc. Shape inflating snack food, the user can choose different types of dryer according to layer, length or energy.



Layers: 3 layers, 5 layers, 7 layers



Power: Electricity/Gas/Diesel



Capacity:100-150kg/h, 200-250kg/h, 260-300kg/h



Applied food: snacks, breakfast cereals, kurkures, corn chips, fried snacks, mini bread pan etc





Characteristics of Electricity Dryer





1. Heat with infrared ray heating tube, raise and lower down temperature quickly, small heat inertia and high heat efficiency. 2. Adjustable transit speed of net belt with accurate temperature control device. 3. Double-roller chain and chain drive make stable and smooth running. 4. Sliding board bottom of dryer for easy cleaning. 5. Suitable to dry non-fried extrusion snacks, nutritional powder,bread crumb, pet food, soybean protein, etc.







Characteristics of Multi-layer Diesel/Gas Dryer





1. High efficient diesel/gas burner can heat swiftly with low consumption and high heat efficiency. 2. Hot wind cycle device makes heat energy equally in the dyer. 3. Adjustable transit speed of conveyor belt with accurate temperature control device. 4. Double-roller chain and chain drive make stable and smooth running. 5. Sliding board bottom of dryer for easy cleaning. 6. Suitable to dry non-fried extrusion snacks, nutritional powder,

bread crumb, pet food, soybean protein, etc.





Photoes















parameter

parameter	seven layers ove	five layers oven	three layers oven
input voltage	380v/50hz	380v/50hz	380v/50hz
installed capacity	36.75kw	36.75kw	24.75kw
power consumption	26kw	26kw	18kw
output	260-500kg/h	260-500kg/h	100-260kg/h
size	5.1*1.2*2.1m	5.1*1.2*2.1m	5.1*1.2*1.8m



 About our company

We, Jinan Guanyuan Machinery Co., Ltd are located in the famous industry city-Jinan city, capital of Shandong Province.

We are professional manufacturer of food extruder and mainly deal with the manufacture, research and development of the inflating food machine. According to the clients’ different requirements, we could offer the whole complete processing line for all kinds of expanded snacks, corn flakes, nutrition powder, and pet food and so on. Our technical assistance will help clients produce high quality products all the time. Depending on our rich experience and professional experts on the extruded food industry, we could offer the most suitable and complete program to assure that your investment will get biggest profit.

Since the establishment of our company, we have always manufacturing our machines according to the authorized standards, by now ,we have got several certificates including CE and ISO9001.

Main products list of our factory

No.	Production Line
1.	Extruded Kurkure / Nik Nak Snacks Food Production Line
2.	Core Filling / Inflating Snacks Production Line
3.	Breakfast Cereals / Corn Flakes Production Line
4.	Extruded Doritos / Tortilla Corn Chips Snacks Food Production Line
5.	Crispy Chips / Sala / Bugles Production Line
6.	Nutrition Powder / Baby Rice Powder Production Line
7.	Nutrition Rice / Artificial Rice Production Line
8.	Bread Crumbs Production Line
9.	Extruded Soya Meat Food Production Line
10.	Extruded Pet / Dog / Cat Food Production Line
11.	Chewing / Jam Center Pet Food Production Line
12.	Extruded Snacks Pellet Food Production Line
13.	Instant Noodles Production Line

Our service

a.) Consultation service before, during, and after sales;

b.) Project planning and design service;

c.) Debugging of equipment until everything is functional;

d.) Management of equipments' long distance shipping from seller's factory to the named place by buyer;

e.) Training of equipment maintenance and operating personally;

d.) New production techniques and formulas;

e.) Provide 1 year complete warranty and life-time maintenance service.
