Home > Products > Stripe floor tile making machine > KBJX 450*225mm stripe stone machine

KBJX 450*225mm stripe stone machine

Name: KBJX 450*225mm stripe stone machine
Brand: KBJX 450*225mm stripe stone machine
Availability: InStock

FOB Price

USD $7,500 - $40,000 / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Tile Forming Machine
Tile Type	Concrete	Use	Floor
Production Capacity	5-8pcs/min	Place of Origin	Jiangsu, China
Brand Name	KBJX 450*225mm stripe stone machine	Model Number	KB-125E/500 450*225mm stripe stone machine
Power(W)	7.5KW	Voltage	110-380V
Dimension(LWH)	346018302750MM	Weight	7T
Certification	ISO9001	Warranty	one year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

KBJX 450*225mm stripe stone machine
500*250mm
2500-3500pcs per 8 hours
cement + stone powder + cobble stone
easy operation

KBJX 450*225mm stripe stone machine

(stripe paver machine, stripe paving making machine, stripe stone machine, stripe block making machine)

Raw material for KBJX 450*225mm stripe stone machine

Raw materials	Specification	Ratio(kg)	Notes
Cement	common	50
Additive	Water-reducing agent	0.5~1.0	optional
Fly ash	Should be qualified	10~30	optional

Stripe pavers / stripe blocks are made by two machines, tile making machine + striping machine = KB-125E/500 + KB-125TWA

KB-125E/500 specification:

Equipment type	Model 500
moulding speed	5-6pcs/min
main frame power	7.5kw
main frame weight	7T
external dimension	330016802700mm

KB-125TWA specification:

External dimension	30008801580mm
Grinding head diameter	Ø338mm
Cutter blade diameter	Ø200mm
motor power	21.8KW
Equipment	pump or tap water
weight	3.5T

Total production line picture for KBJX 450*225mm stripe stone machine

equipments composed for KBJX 450*225mm stripe stone machine

1	Moulding machine	1 set
2	constant feeder machine	1 set
3	blender	1 set
4	elevator machine	1 set
5	air compressor	1 set
6	stripping machine	1 set

work flow of KBJX 450*225mm stripe stone machine

Work flow: Elevating--- Mixing --- Fixed-quantity filling --- Pressure forming --- Mould unloading --- Forming tiles --- Onto the tiles shelf ---Maintenance (24 hours) --- Stacking --- Natural maintenance --- Stripping lines --- Finished products.

finished stripes

Multi-functional samples of tiles by chaning mould

Factory:

for details information, pls kindly feel free to contact following:

Contact Us

Yancheng Kebo Hydraulic Machinery Manufacturing Co., Ltd.: Contact nameKebo Liu
Chat Now; Phone86-515-88299511; AddressNo.8 Xinwei Road,Xinyang Economic Zone, Yancheng, Jiangsu

*Email
Please enter Your valid email address.
*To

Kebo Liu
*Message
Your inquiry content must be between 20 to 5000 characters.
Please enter a correct verification code.
