Unique best quality brine water slice ice machine
- 3000 Set / Sets per Month
- Zhejiang / Shanghai / Tianjin Port
- Credit Card
Product Details
Condition: | New | Capacity: | 8tons/24h | Place of Origin: | Shaanxi, China |
Brand Name: | TOPTION | Model Number: | TPPB8.0Z-DS/F | Ice Shape: | Flake Ice |
Voltage: | 380V | Power(W): | 22.79kW | Dimension(L*W*H): | 2300*1650*1525mm |
Weight: | 1300kg | Certification: | CE | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Unique best quality brine water slice ice machine
Application Field:
1. Aquatic product processing
2. Medium and large chain supermarket
3. Fresh preservation and cooling field application
4. Concrete cooling project
5. Medical facilities
6. Dye chemical industry
7. Mine temperature reduction
Industrial Flake Ice Machine Features:
·Reasonable Design
TOPTION ice machine is with integrated structure design, and all our equipments are designed on the basis of modules, so the spot maintenance is simple by removing the old parts and install the new ones. Furthermore we always give consideration to how to conveniently move the ice machine to other places.
·High Stability
TOPTION always aims at researching and manufacturing high efficient and energy-saving refrigeration system; the flake ice machine adopted international ice machine processing technology and experience, it can produce quality flake ice and constantly operate over 20,000 hours without failure.
·Sanitation
TOPTION flake ice machine is made of stainless steel, pure aluminium alloy or PE material; flake ice is made inside evaporator so it is not exposed to ambient conditions, its hygiene level reaches international standards of HACCP and FDA.
·Water & Energy Saving
TOPTION flake ice machine recycles all unfrozen water back to the ice machine so as to ensure all water is converted to ice and save water resources; Our unique evaporator processing technology makes it better heat exchange efficiency and saves more energy, moreover our patented internally-scraping ice scraper can help reduce energy consumption.
Industrial Flake Ice Machine Technical Specifications | |||||
Model | Capacity (tons/24h) | Refrigeration Capacity (kW) | Total Power | Weight | Dimension (L*W*H)(mm) |
TPPB3.0Z-DS/F | 3 | 19.17 | 9.82 kW | 470 kg | 1615*1015*1120 |
TPPB5.0Z-DS/F | 5 | 28.8 | 15.28 kW | 1100 kg | 1850*1370*1373 |
TPPB8.0Z-DS/F | 8 | 43.2 | 22.79 kW | 1300 kg | 2300*1650*1525 |
TPPB10Z-DS/F | 10 | 51.5 | 29.17 kW | 1500 kg | 2300*1650*1745 |
TPPB15Z-DS/F | 15 | 106.6 | 55.47 kW | 3200 kg | 3200*2010*2061 |
TPPB20Z-DS/F | 20 | 113.6 | 65.57 kW | 4200 kg | 3400*2180*2370 |
TPPB25Z-DS/F | 25 | 154.8 | 77.25 kW | 5000 kg | 3800*2540*2452 |
TPPB30Z-DS/F | 30 | 184.5 | 92.40 kW | 6000 kg | 4500*2540*2772 |
TPPB35Z-DS/F | 35 | 219.5 | 108.35 kW | 6500 kg | 4780*3010*2658 |
TPPB40Z-DS/F | 40 | 253.8 | 121.85 kW | 7500 kg | 5000*3010*2818 |
TPPB50Z-DS/F | 50 | 329.1 | 160.15 kW | 10000 kg | 5000*3010*3158 |
TPPB60Z-DS/F | 60 | 393.7 | 189.35 kW | 12000 kg | 5500*3010*3358 |
brine water slice ice machine pictures
brine water slice ice machine producing process
brine water slice ice machine packing
