Product Details
Place of Origin | Henan, China | Material | Other, Glass or ceramic |
Product Description
CE certificate high quality plasma cleaning system
Featrues of plasma cleaning system
1. Environmental technologies: plasma process is the role of gas - solid coherent reactor consumes no water resources, no need to add chemicals and no environmental pollution.
2. Wide adaptability: regardless of processing substrate type, such as metals, semiconductors, oxides, and most of the polymer material can be a good deal;
3. Low temperature: close to room temperature, particularly suitable polymer materials, have a longer retention time and a higher surface tension than the corona and flame method.
4. Multifunctions: it involves only a shallow surface of polymer materials (10 -1000A), while preserving the characteristics of the material itself can give it one or more new features;
5. Low cost: the device is simple, easy operation and maintenance, continuous operation,a few bottles of gas can replace thousands of kilograms cleaning fluid
6. The whole process technology can be controlled: all the parameters can be setted by the computer and data recording
7. Treated geometry Unlimited: Big or small, simple or complex, parts or textiles can be processed.
Technical parmaters of plasma cleaning system
Model no. | CY-P10L-B | CY-P5L-A | CY-P2L-A | CY-P2L-B | ||||
Display | LCD touch screen | LED button screen | ||||||
Power supply | AC 220V 50Hz | |||||||
Working current | plasma cleaner working current less than 1.2A | |||||||
Radio frequency power | 100-400w, adjustable | < 200w, adjustable, or customized | ||||||
RF frequency | 13.56MHz(offset less than 0.4KHz) | 40KHz(offset less than 0.2KHz) | ||||||
Characteristic impedance | 50 Ohm,automatch | |||||||
Chamber capacity | 10L | 5L | 2L | 2L | ||||
Vacuum degree | 60Pa-100Pa | 10Pa-100Pa | 30Pa-100Pa | 10Pa-1000Pa | ||||
Cleaning time | 1~6000ml adjustable | |||||||
Gas flow speed | 10~100ml | |||||||
Control mode | Manual control or Programmable control | |||||||
Vacuum pump | CY-4C | |||||||
Vacuum chamber temper. | less than 65℃ | |||||||
Cooling type | forced air cooling | |||||||
Equipment list | plasma cleaner:1set; vacuum pump: 1set; vacuum high-pressure hose: 1pc;O type card: 4pcs;protective tube(0.2A,1.5A): each 3pcs. |
Pictures show of plasma cleaning system
Payment
T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC
Warranty
Main product is 12 month, except wearing parts.
Wearing parts as below:
Door stopper, glove, crucible tongs,crucible, bearing board.
Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in the research and development, design, manufacturing and sales of equipment used in scientific researches. Independence and innovation is the company's tenet.
We are looking forward your order of plasma cleaning system
