thrust needle roller bearing AXK4060

Tube & Box Marking:1. Laser marking on outer face of outer ring like Brand, 2.Print Brand on Rubber/Metal shield..

Specifications

thrust needle roller bearing AXK4060:
1.Single direction axial
2.high loading capacity
3.High stiffness
4.High speed

  thrust needle roller bearing AXK4060

Axk Needle Roller Bearing



These bearings can be used without thrust washers when the faces of adjacent machine components can serve as raceways, allowing the machine to be even more compact. These bearings provide a high degree of stiffness and are most suitable where high accuracy is required at high speeds and under fluctuating heavy loads, such as machine tools and high-pressure pumps.







Product details





Thrust Needle Bearing (AXK series)





Code	Size(mm)			Rating Load(N)		Rotate Speed Limit(r/min)		Weight
	dw	Dw	h	Ca	Coa	grease lubrication	oil lubrication	(kg)
AXK1528	16	28	2	9650	33500	4500	12000	0.003
AXK1730	18	30	2	10200	36500	4300	11000	0.003
AXK2035	21	35	2	11200	43000	3600	9000	0.005
AXK2542	26	42	2	12500	54000	2800	7000	0.006
AXK3047	32	47	2	14000	65500	2400	6300	0.007
AXK3552	37	52	2	15300	76500	2000	5600	0.008
AXK4060	42	60	3	24500	110000	1800	5000	0.016
AXK4565	47	65	3	26500	125000	1600	4500	0.018









 Application



Hot-selling



AXK0414TN    AXK0515TN      AXK 6X17X2        AXK 0619         AXK 6X23X2  AXK7X15X1.5TN     AXK 0821TN

AXK10X22X2   AXK 1024         AXK 10X27X2.5   AXK 1226TN    AXK 1528      AXK16X35X4.762

AXK17X33.5X3   NTA-1220      AXK 2035            AXK 2542/P5   NTA-1828     AXK 30X42X2.5       S3401G-013

AXK 3552      AXK43X65X4.9    AXK 5070            AXW 30          AXW 35         AX W40  AX W45
