Specifications
1.Through the ISO9001 certification ;2.10 years pipe production management;
3.Application to land drainage.
Product use:
l golf course; Sports venues (All kinds of arena) ooze and drainage pipe
l foundation treatment ,tunnel ooze and drainage pipe
l farmland ,Water conservancy ooze and drainage pipe
lroads , Highway ooze and drainage pipe
l greening tube.
Product Specifications:
Diameter mm | SG50 | SG63 | SG75 | SG80 | SG110 | SG160 | SG200 |
structure type | single | single | single | single /double | Single/double | single/double | single/double |
Material | PE,PP,PVC,PET | PE,PP,PVC | |||||
Reference diameter mm | 41 | 55 | 67 | 71 | 100 | 148 | 182 |
Feed water area cm2/m | 24 | 24 | 24 | 24 | 80 | 80 | 80 |
Local punched Feed water area cm2/m |
|
|
|
| 60 | 60 | 60 |
length | 100m/ coil | 20-50m/ coil or 6m/ root | |||||
Product features:
ladopts wave structure, reduce the weight of pipe, at the same time, improve the stiffness of the tube, and have high hoop stiffness/weight ratio;
the product is light ang flexible, has low friction coefficient,easy to Installation laid and transportation.
l Delivery length is convenient to customed.
lhas high physical and mechanical property, high pressure, impact resistance, heat resistance, and corrosion resistance.
The main technical indexes:
lvertical condensation to 40% of the outer diameter, immediately unloading, sample is not rupture or layered
ltemperature At 0 °C, the height of 1 M conditions, for 1 Kg weight hammer, impact 10 times, should be OK more than nine times;
luniform and smooth inwall ,through hole localed lower than 1/2 of The height of the troughs, the number of through hole which higher than 1/2 of The height of the troughs is less than 10% of the total;
lpermeable area ≥45cm2/M
llongitudinal retraction rate ≤3.0%
lbending degree %≤2
lring stiffness≥6.3KN/m2
Product pictures
In the corrugated tube outsourcing a layer of geotextile, prevent soil plugging holes :
the left of the corrugated top is a circle, and the right corrugated top is square
The left is the single wall corrugated pipe, the right side is double-wall corrugated pipe
Holes can be circular or rectangular :
Special specifications can also customized , Welcome to inquire negotiate!
