Home > Products > END MILL GRINDER > End Mill Grinder MR-X3
End Mill Grinder MR-X3
- 50 Set / Sets per Month
- Shanghai/Ningbo
- T/T Credit Card
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | MEIRI MACHINE TOOL | Model Number: | MR-X3 |
| Power Source: | Electricity | Type: | Die Grinder | Variable Speed: | No |
| Rated Input Power: | 180W | Disc Diameter: | 125mm | Rated Voltage: | 220V |
| No-Load Speed: | 5300RPM | Frequency: | 50HZ | Disc(Wheel) Type: | Grinding Disc |
| Dimensions: | 35*23*24cm | Weight: | 12kg |
Product Description
Specifications
1. End mill grinder.2. Portable end mill grinder and easy operation.
3. End mill grinder with CE certification.
1. Portable idiot end mill grinder, can grind 2-flute, 3-flute, 4-flute, 6-flute end mill.
2. Grinding is accurate and rapid, easy operation with no skill to grind.
3. With Taiwan diamond grinding wheel, only one piece can complete all procedures.
4. It can be equipped directly with an accurate angle and long service life.
Model: | MR-X3 |
Diameter: | Φ4-Φ14 |
Power: | 220V/180W |
Speed: | 5300rpm |
Point angle: | 0°-5° |
Dimension: | 35×23×24cm |
Weight: | 14kg |
Standard Equipment: | One piece grinding wheel :CBN (for HSS)×1 |
Six collets: Φ4,Φ6,Φ8,Φ10,Φ12,Φ14 | |
Two collet chucks: 2,4 flutes ×1 piece; 3,6 flutes×1 piece | |
Optional Equipment: | grinding wheel :SD (for Carbide) |
1.Q: What is your MOQ of this item?
A: 1 set
2.Q: What is the delivery time?
A: 15-20days after receiving your T/T or Western Union.
3.Q: Is it all right to make customer's own brand name?
A: OEM is ok.
4.Q: Where is your Loading Port?
A:Ningbo/Shanghai,China port.
5.Q:Are you a manufactuer or trading company?
A:We are a manufactuer specialized in drill bit grinder,end mill re-sharpener,screw tap re-sharpener,lathe tool grinder,saw blade re-sharpener,chamfer,universal cutter grinder,tapping machine and electrical tapping machine more than 10 years.
6. Q:How many exhibitions will you participate in every year?
A: As last year we took part in 98 exhibitions, which include the 10 exhibition in the other countries.
