Besr selling electromagnetic interactive whiteboard

Model

DB-85ENS-D02

DB-95EWS-D02

DB-101EWS-D02

Physical Diagonal

85 Inch

96 Inch

103 Inch

Active Diagonal

81 Inch

91 Inch

98 Inch

Active Area(mm)

1672×1190

1990×1190

2202×1190

Physical Dimensions(mm)

1760×1296×37

2078×1296×37

2290×1296×37

Packed Dimensions(mm)

1859×1389×120

2177×1389×120

2390×1389×120

Aspect Ratio

4:3

16:10

16:9

Net Weight (KG)

14

19

21

Packing Weight (KG)

25

32

34

Resolution

14100×10100

16800*10100

18600*10100

Working Principle

Electromagnetic Induction

Writing Way

Electronic pen with right mouse key and eraser key.

Dual User Function and Pen Gesture Recognition Function

Two users can write freely on the screen without interference, and it supports pen gesture recognition, such as turning page by sliding electronic pen.

Pen Holder

It was attached on the side frame and it can hold two pens.

Calibrate Technology

4 points calibration. Calibrate precision: ≤0.05mm

Precision

0.05mm

Surface Material

Low glare PET material providing an efficient projection surface.

Back Material

Polycarbonate sheet.

Frame Material

Aluminum alloy.

Interface

USB 2.0

Power Requirement

USB powered device.

Power Consumption

≤2W

Tracking Speed

12m/s

Shortcut Key

18 shortcut keys on dual sides

Operating System

Windows XP, Win 7 and Vista.

Temperature

Working: -10°C~50°C, Storage: -25°C~70°C

Humidity

Working: 30%~80%, Storage: 10%~90%

Mounting Way

Wall mounting, mobile floor stand mounting , push-pull blackboard stack mounting

Standard Accessories

Driver CD 1 pc, USB cable 1 pc, USB adapter 1 pc, electronic pen 2 pcs, pen holder 1 pc. wall-mounted bracket 1 set.

Optional Accessories

Pen holder, pointer, mobile floor stand, mobile floor stand with short throw projector bracket, projector bracket.

Certificates

C-TICK, CE, RoHS, FCC, ISO9001: 2000

Life Time

7-10 years

Warranty Period

Interactive whiteboard: 5 years, accessories: 1 year.
