3 axis cnc stamp molding machine

1400mmX1200mmX1700mm
Fumigation wooden boxes for exporting

Specifications

3 axis cnc stamp molding machine
1. NK260 system
2. 2.2kw spindle
3. servo motor
4. CE,SGS,ISO



                              3 axis cnc shoes molding  machine



Our CNC milling machine includes FASTCUT-4050 professional type, FASTCUT-6060 compact type, FASTCUT-6090 simplified type, and so on. Our product features a cast iron body and three-axis ball screw driving. It also features a high processing speed, high precision, simple maintenance and low failure rate. Thanks to the industrial grade ball screw, our CNC milling machine could have great transmission efficiency, enhanced precision and good performance. In addition, servo motor or stepper motor is used as the power source of the product, and it could precisely control the stroke, achieve good accuracy and lower the noise. Meanwhile, the software compatibility is quite good. Our products can be used with multiple CAD / CAM design softwares, such as TYPE3, Artcam, JD, Wentai carving, UG, MasterCAM, PowerMill and others.



Most engraving machine is mainly used for carving, while it is not suitable for processing hard materials. In order to meet the needs of customers, our CNC milling machine combines the function of engraving and milling to process a variety of materials, especially hard materials. It is a high efficiency, high precision CNC machine. Considering the cost, our product is generally small, while it could process materials with maximal size of 600 * 900 * 200mm.



APPLICABLE INDUSTRIES



MDF, solid boards, composite boards, laminated panels, dressed lumbers, corks, original wood, PVC, gypsum,doublecolor boards, aluminous model boards, lotus plates, organic glass, acrylic, ABS, brahman’s stones, sandstones, marble, granite, all kinds of artificial stones, light box pieces, LGP, ox horns, all kinds of metal, surface processing and cutting of all kinds of rigid plastics



APPLICABLE MATERIALS



Our CNC milling machine is widely used in mold industry. It could carve a variety of metal mold, wood mold, matrix, wooden aviation mold, etc. The materials it mainly processes are die steel, copper, aluminum, and other metals.



 PRODUCT FEATURES



1.Whole cast-iron structure, steady structure, high rigidity,precision 0.01mm.
2.Three axis all use Germany ball screw and Taiwan linear orbits, also installed with Japan bevel
math bearing for ball screw to make sure the accuracy and reposition precision.
3.Adopt table movement to keep stable.
4.Adopt high-speed water cooling variable frequency motor, big torque, strong cutting, high-frequency , long life, can be long time continuous working
5.Mold adopts high-end configuration, cast iron structure, Germany ball screw, and use table movement to keep machine stable. And it include semi-enclosed type and totally-enclosed type,you can choose the one you need.



SPECIFICATIONS



FASTCUT MODEL	FASTCUT-3030 CNC Milling Machine
Working Area (X*Y*Z)	400X500X30mm(11.8X11.8X1.18 inch)
Table size	650X750mm
Processing accuracy	0.015mm/300mm
Repositioning accuracy	0.015mm/300mm
Lathe structure	Cast iron
Table structure	Cast iron
Spindle	2.2KW Constant power variable speed , water-cooled
Spindle rotating speed	0-24000rpm/min
Max Moving Speed	12000mm/min
Working speed	0-8000mm/min
Driving mode	XYZ-Ball screw
Voltage	AC220V/50Hz
Max. Power consumption	3.5KW
Feeding Height	300mm
Drive motor	Servo
Command	de , mmg , plt , uoo,HPGL
Compatible Software	ArtCAM, masterCAM UG software
Certificate	CE,FDA
Pack dimensions	1300mm X 1300mm X 2000mm wooden trunk
Net weight	1800KG





SAMPLES







MACHINE PARTS PICTURES

FACTORY SHOW

PRODUCT CERTIFICATE

COOPERATIVE CUSTOMERS

COOPERATIVE SUPPLIERS







COMPANY ADVANTAGES

1, First-class factory meets international production plant's standard, ten years' manufacture and export experiences

2, Own most advanced domestic cnc machining production equipments

3,20 professional high-end R&D technical staff, and can provide multiple languages and real-time online technical support

4,5-9 days machine production time, one year warranty and lifetime free maintenance

5,OEM and ODM services avaliable

6,Same quality, our price and service are better;Same price, our quality and service are better

7, with CE, FDA, SGS, ISO9000 certifications

PRODUCTION PROCEDURE

CONTACT US

FAQ

In order to help you choose the best suitable machine, please try to reply my questions below, thanks

Q1: What about your material , wood or acrylic or ?

Q2: The size of your mateiral , length ? Width and thickness?

Q3: Do you want to cut or engrave your material ? Or both cut&engrave ?

Q4: What machining effection do you want to get ? It is better you can send sample pictures to me .

Q5: The machine choose 220v or 110v or ?

Q6: what about your nearest sea port
