Portable toilet with trailer,trailer toilet, Portable Toilet, Movable trailer Toilet

Specifications

Trailer toilet,Used trailers
1, Portable toilet with trailer
2, Portable Toilet
3, Movable Toilet
4, ISO9001

Trailer toilet , Used trailers

1, Portable toilet with trailer

2, Trailer toilet

3, Movable Toilet

4, ISO9001



Product features:

1. Use modular toilet as base constuction material overthrows the traditional mode of construction and creates a new, green and integrated living concept.

2. fast assembling & disassembling and convenient relocation and transportation.

3.various decoration styles for your choice all house type designed by experienced designer

4.variouse green healthy decoration materials and integrated furnishing solutions for you choice

5.experienced building team to assist installition and provide instruction for customer reference











































  Mobile Toilet



Item	Sort	Name	Specification and parameter
1	product model	standard intensity	standard product,the dimension can be designed by the customers’ requirement
2		removable performance	the toilet are divided into components in transportation and builded into a whole hoisted toilet
3	specification	length	customized
4		width	customized
5		height	customized
6		clear height indoor	2200mm
7	standard component	ground beam	3mm galvanized angle iron
8		roof beam	3mm galvanized angle iron
9		central column	4mm galvanized angle iron
10		column on the corner	4mm galvanized angle iron
11		wall panel	60mm double-faced coloured steel sandwich board
12		roof panel	100mm double-faced coloured steel sandwich board
13		secondary beam	Z-shaped galvanized steel iron
14		roof insilation	110mm glass wool
15		floor	18mm plywood or fire-proof sandwich board with the filling of 50mm polystyrene and sealed by 0.326mm galvanized board
16		door	alumiinium alloy door,750mm*2000mm
17		window	plastic steel swing window with two layers glass,
18	elective component	floor	composited wooden floor
19		door	aluminium alloy door
20		electronics,water supply and drainage	the plan,design and construction can be provided according to the related law of the country
21		furniture and appliance	custom made
22	designing parameter	roof load	0.5KN/sqm(If the criteria were exceeded, it can also load by reinforcing the structure)
23		wind pressure load parameter	scale of wind force.10 grade,wind pressure.0.5KN/sqm,designing wind speed .28m/S(Chinese standard)
24		seismic fortification intensity	magnitudes 7
25		suitable temperature	suitable temperature scope.-50°C~+50°C
26	contruction	contruction tools	convenient construction,the tools are spanner,bolt driver and so on
27		construction efficiency	4 experienced technicians can build 6-8 protable toilet
28	transportation	container trunk	loading in 40HC,20ft sea container



Detailed parameters:

The details and specifications of the portable toilet are as follow:

Wall and Roof Materils :    Sandwich panel

Structure              :      light steel structure portable toilet

Window               :      Aluminium alloy window or Plastic steel window

Door                    :      Aluminium frame sandwich panel door.

Size                      :      any size

Payment term       :      50% T/T,against order and the balance paid before delivery.

Delivery time        :      Within in one month after receipt of you full payment.



Our Service:

we can provide the service of installayion supervisin and training by extra.



About us price:

If you are interested in our portable toilet, please feel free to contact with me. I am sure the professional design, reasonable price of our portable container house will be most attractive. Hope we can do business together and set up long term cooperation!
