DZ601-48 Single Phase Energy Meter Test Equipment

Specifications

1. 48 positions meter test device
2.Half meter reading & half-calibratin
3.ISO 9001 verified
4.Accuracy class: 0.05, 0.1, 0.2

DZ601-48 Single Phase Energy Meter Test Equipment

The main features:

:1-New type aluminum material rack , special keyboard operation

2-The tested meters may be same specification but different constant , the meter such as

 Single- phase mechanical ,electromechenical and Electricity meters Can be tested simultaneously

3-Automatic capture black spots , and carry out starting test and no Ioad test

4-Automatic short current circuit of the idle meter position , self lock meter mounting

seat , quick wiring connection

5-Automatic turning up of all the scanning head together

6-Automatic alarm protection from the voltage short circuit and the current open circuit

7-Automatic checking of the meter constants , check register display

8-Fully automatic meter testing controlled by computer with friendly-user software

Intelligent data processing and network data sharing

9-support bar code reading meter information

10-Randomly setting of report table and certificate formats

1 I-The unit of measuring ambient temperature and relative humidity is optional

12- Automatic multi-time section burden controlled by PC





item		Class 0.05	Class 0.1
Equipment accuracy class		0.05 for active	0.1 for active
Standard meter accuracy class		0.02(0.05)	0.05
Measure repeatio (cosφ=1.0)		0.005	0.007
Current range		0.01A, 0.5A1.0A2 .5A 5A10A20A50A100A
Voltage range		220V
Output power	voltage	600VA
	Current	960VA
Voltage adjusting	Adjusting range	0~120%
	Adjusting resolution	10%1%0.1%0.01%
Current adjusting	Adjusting range	0~120%
	Adjusting resolution	10%1%0.1%0.01%
Phase adjusting	Adjusting range	0.00°~359.9°
	Adjusting resolution	10°1°0.1°0.01°
Frequency adjusting	Adjusting range	45.00~65.00Hz
	Adjusting resolution	10Hz1Hz0.1Hz
Waveform distortion		<1.0%
Power stability		<0.05%
Display Accuracy class	Voltage	±0.2%	±0.2%
	Current	±0.5%	±0.5%
	power	±0.5%	±0.5%
	frequency	±0.2%	±0.2%
	phase	<0.2°	<0.2°
Working power		220V±15%,50/60Hz
Dimension	Meter rack
	Power case

Technical Index:
