AEEF series IEC standrad three-phase induction motor

Specifications

1. Model: AEEF series
2. Rated Voltage: 380V
3. Rated frequency: 50HZ, 60HZ
4. electric motor with competitive price

                      AEEF series IEC standrad three-phase induction motor





1. Model: AEEF series
2. Rated Voltage: 380V
3. Rated frequency: 50HZ, 60HZ
4. electric motor with competitive price

Advantages:



Advantages:

AEEF series motor is three-phase, totally enclosed and fan-cooled electric motor with squirrel cage, IP54, insulation, Class B ( other voltages and cycles insulation class F are available on request. )

Operating conditions:

1.Ambient temperature: -15°C<q<40°C

2. Altitude: Not exceeding 1000 meters

3. Rated voltage: 380V

4. Rated frequency: 50HZ/60HZ

5. Connection: Star-connection for 3kw and below Delta-connection for 4kw and above

6. Duty/Rating: Continuous ( SI )

7. Insulation class: Class B/F

8.Protection: IP44/IP54 9. Cooling method: IC0141

FUAN LIYUAN ELECTRICAL MACHINERY CO.LTD, professionally produces the motor, generator, water pump of different series, which have been sold to all the China and exported to more than 100 countries in America, Europe, Southeast Asia and so on, with the high quality and best prices, the products are warmly welcome by the clients from the home and abroad. The main products are as follows: Y, Y2, AEEF, Series three phase induction motor. YC, JY series heavy-duty single-phase induction motor. MY, MG, ML, MS series induction motor with the aluminum housings. YCG series induction motor with the steel-plate housings. ST, STC series generator , TZH series Compound Excitation generator. SFS, GFS series low noise diesel generating set. LY950...LY6500 series gasoline generator, and IDB, QB, JET... Series water pump .
