Perforated Grass Soil Geocell
- 45000 Square Meter / Square Meters per Month
- QingDao
- T/T L/C D/P D/A Credit Card PayPal
Product Details
| Place of Origin: | Shandong, China | Brand Name: | Ruiheng | Model Number: | RH-geocell |
| Material: | PP, Other, PP, PE |
Product Description
Geocell Introduction
Geocell is reinforced by high intensity HDPE broadband, after the powerful welding face to become a reticular lattice room structure. It retractile,transportation can shrink fold super to,when using ,open and filling earth-rock,or concrete materials,constitute has strong lateral restrictions and taking degrees structures ,it can be used as a cushion,dealing with weak foundation bearing capacity , also can be laid on slope surface slope protection structure constitute, still can be used to build retaining structures,etc
Geocell Specifications
Perforated Grass Soil Geocell
Model | Expanded Size (m) | Height (mm) | Welding distance (mm) | Yield strength of cell (Mpa) | Seam Peel strength (N) | Thickness (Smooth or Textured) | Perforated percentage |
TGLG500/400 | 5.7X6.22 | 50 |
330
400
500 |
≥20 | ≥500 |
Smooth sheet: 1,1.2,1.5,2mm
Textured sheet: 1.2,1.7,2mm |
15%, 20%, 40% , 60%, 80% |
TGLG75/400 | 5.7X6.22 | 75 | ≥750 | ||||
TGLG100/400 | 5.7X6.22 | 100 | ≥1000 | ||||
TGLG150/400 | 5.7X6.22 | 150 | ≥1500 | ||||
TGLG200/400 | 5.7X6.22 | 200 | ≥2000 | ||||
TGLG240/400 | 5.7X6.22 | 240 | ≥2400 | ||||
Remarks: Welding distance can be made: 330mm, 400mm, and 600mm, with various mesh sizes.
| |||||||
Geocell Applications
Perforated Grass Soil Geocell
A.solid railway roadbed
B.highway's soft foundation
C.withstand truck force embankments,retaining wall
D.running shallow river
E.pipeline and the sewer's support structure
F.to prevent landslides and load force by the hybrid wall
G.to use independent wall ,wharf ,breakwater and so on
H.to govern the desert, beaches and the riverbed , banks
Perforated Grass Soil Geocell
Our Other Products
If you want to learn more about our products,please click here.
What We Can Do For You
Perforated Grass Soil Geocell
1. We have our own factory. We can provide what you want in competitive price.
2. Our company provides before-sales, in-sales and after-sales services with heart and soul in engineering construction and products selection.
3. Our company is in strict accordance with national standards and related standards. Our company passed ISO9001 and BV quality system authentication.
4.We have been exporting for 5 years.
We can provide necessary certificates to make customs clearance easier for you.
We know well about container. We can make advice for you to reduce freight without damaging goods.
5.We can provide Certificate of Origin. For Southeast Asia, FORM E and FORM A. For Chile, FORM F. For Africa, C O.
We are looking forward to your sincere cooperation. If you have any question, please feel free to contact us.
