NEW forland 4ton LHD/RHD crane with truck
- 500 Set / Sets per Month
- any port in china
- T/T
Product Details
| Condition: | New | Application: | loading and unloading, lifting work | Rated Loading Capacity: | 3000-5000 |
| Rated Lifting Moment: | 6.7M | Max. Lifting Load: | 3200-4000kg | Max. Lifting Height: | 11.5m |
| Span: | 6-9m | Place of Origin: | Hebei, China | Brand Name: | JDF |
| Model Number: | JDF5070JSQ | Certification: | 3C iso | Warranty: | one year |
| After-sales Service Provided: | Overseas service center available |
Product Description
Specifications
NEW forland 4ton LHD/RHD crane with truck1.High Quality Chassis, competitive prices
2.3C ISO BV approved
NEW forland 4ton LHD/RHD crane with truck
1.We are professional manufacturers NEW forland 4ton LHD/RHD crane with truck to do the special vehicles . We are supply all brands of special truck , north benz(beiben) , Faw , Foton , Shaanxi ,Sinotruck , Jac , Jmc , Isuzu ,Dongfeng all available .
2.the drive type could be 4x2 , 4x4 , 6x2 , 6x4 , 6x6 , 8x4
3.We can provide LHD (left hand drive) or RHD (right hand drive) vehicles .
Product advantage:
1. crane with truck Factory export department directly sale
2.Export experience more than 12 years
3.Cheap / competitive price, high quality ,you get more than your paid
4.With CCC, ISO , BV approved
5. The heart of the service, rational design
Product parameters:
Product model | truck crane for good sale | |
Product parameters | Total mass(Kg) | 8495 |
Rated weight(Kg) | 3000-4000 | |
Curb weight(Kg) | 4590 | |
Overall dimension(mm) | 6100*2190*2950 | |
Carriage dimensions (mm) | 3500*2050*550 | |
| ||
Chassis parameters | Chassis model | BJ1081 |
Fuel type | Diesel | |
Emission standard | Euro 3 | |
| ||
Engine parameters | Engine model | CY4102-C3F |
Manufacturer | chaochai | |
Displacement(ml) | 3834 | |
Power(Kw) | 91 | |
| ||
Main Parameters
| Rated person of Cab | 3 |
Number of axles | 2 | |
Wheelbase(mm) | 3900 | |
Axle load(Kg) | 3920/4380 | |
Tires No. | 6 | |
Tyre size | 8.00-16 | |
Max. speed(Km/h) | 95 | |
Approach angle /Departure angle (°) | 19/16 | |
Front overhang /Rear overhang (mm) | 1015/1525 | |
Front track/Rear track(mm) | 1385/1425 | |
PRODUCT DISPLAY :
WORKSHOP AND CERTIFICATION:
Contact Us
- Hubei Jiangnan Special Automobile Co., Ltd.
- Contact nameDarwen Dang Chat Now
- Phone0086-0722-18727980799
- AddressNO.1 Xingguang Industrial Park, North Outskirt Suizhou,Hubei
-
