APP08 Hydraulic Power package Press

Specifications

Pneumatic Clinching Machine
Rugged,efficient
No damage,no distortion
ing force:1000KN
Max.total stroke:100mm

                                                            APP08 Hydraulic Power package Press



Model FL08 Litelocker Press is a solid construction built with advanced technologies unit driven with Shineeast-Powerpackage. It can firmly join two or three sheet metal by means of a drawing-pressing process. And it does so without any damage to the surface, purely by cold forming. In addition, it assures you with high productive efficiency as well as high precision and reliability meeting with air blower and pipeline industries requirements.



Components

• Frame(cast steel)
• Shineeast-Powerpackage  (Series H, P and FT for option )

Our standard function modulars as well as the control units are provided for your specific application requirements.



Optional Modular

• Two hand safety control modular
• Coupling flange
• Intelligent monitoring
• Processing position indicator



Advantages

• Compact and rugged construction
• Cast steel support provides for solid construction as well as long life expectancy
• On-time monitoring and documented
• Processing position indication with laser point indicator
• No heating are required
• No damage to the precoated surfaces or plating sheet metal
• Low noise level
• Low energy consumption and minimum maintenance requirements
• Save on investment
• Available for the joining of various connecting pipes in rectangle or circular shape
• Almost unlimited number of possibilities are realized with variety specs of moulds,tool fixtures and punching heads



Technical parameters

Throat depth	400mm
Min. diameter of section	80mm
Thickness
Galvanized sheet	2×0.5-1.5mm
	3×0.5-1.0mm
Stainless steel sheet	2×0.5-1.0mm
Aluminum plate	2×0.5-1.5mm
Mould-shut height	50mm
Power stroke	6mm
Total stroke	100mm
Driven air pressure	6bar

Please consult us for printable dimensional drawing and technical parameters for Model FL08.
