2014 hot sale low voltage heat shrinkable cable termination kits cable joints indoor low voltage cable accessory

Specifications

1. Exported to many countries
2. Best manufacturing equipments
3. Professional overseas sales team
4. Good quality and prices

CN - NRS CN - WRS CN – JRS heat shrink series cable accessories

CN - NRS CN - WRS CN – JRS heat shrink series cable accessories is applied to 35kv and below rubber cable. Heat shrink cable accessories is using import multiphase polymer, it’s the update products of wrapped type cable accessories. With convenient installation, keep on suitable radial pressure on the cable body, interface characteristic is good. the parameter type stress control tube to improve the distribution of the electric field, which can effectively solve the cable outer shield section in electric stress concentration problem. The electrical properties are improved from wrapped type cable accessories to ensure the safty and reliable operation. The main components are tubular, basically includinig stress tube, insulation tube, three fingeed tube, sealed tube protective sleeve, etc





Main performance and structure features

   Technical performance: meet BS EN 50181, IEC60502, GB/T12706 requirements.

   Heat shrink raw materials: stress tube is parameter type, well-distributed electric field at the insulating cable cut off place. Insulatingtube has insilation effect, protective sleeve has protection effect. Product heat shrink is quite stable, can shrink to the orginal size in heating condition, the residual deformation is small. All the products are processing forming in the factory. There’s no need to use fire, no special training, installation is simple and fast.

   It has resistance to filth, aging, and good waterproof, with superior cold heat resistant performance.

   Surface is smooth and beautiful.





No	Name	Model	Voltage	Cable Cross section	Voltage	Cable Cross section	Remark
1	Heat shrink indoor terminal	CN-NRS-8.7/15-1	6/10	25~70mm²	8.7/15	25~50mm²
		CN-NRS-8.7/15-2		95~185mm²		70~150mm²
		CN-NRS-8.7/15-3		240~400mm²		185~300mm²
		CN-NRS-8.7/15-4		500~800mm²		400~630mm²
2	Heat shrink outdoor terminal	CN-WRS-8.7/15-1		25~70mm²		25~50mm²
		CN-WRS-8.7/15-2		95~185mm²		70~150mm²
		CN-WRS-8.7/15-3		240~400mm²		185~300mm²
		CN-WRS-8.7/15-4		500~800mm²		400~630mm²
3	Heat shrink middle joint	CN-JRS-8.7/15-1		25~70mm²		25~50mm²
		CN-JRS-8.7/15-2		95~185mm²		70~150mm²
		CN-JRS-8.7/15-3		240~400mm²		185~300mm²
		CN-JRS-8.7/15-4		500~800mm²		400~630mm²
4	Heat shrink indoor terminal	CN-NRS-26/35-1	21/35	50~150mm²	26/35	50~120mm²
		CN-NRS-26/35-2		185~300mm²		150~240mm²
		CN-NRS-26/35-3		400~500mm²		300~400mm²
		CN-NRS-26/35-4		630~800mm²		500~800mm²
5	Heat shrink outdoor terminal	CN-WRS-26/35-1		50~150mm²		50~120mm²
		CN-WRS-26/35-2		185~300mm²		150~240mm²
		CN-WRS-26/35-3		400~500mm²		300~400mm²
		CN-WRS-26/35-4		630~800mm²		500~800mm²
6	Heat shrink middle joint	CN-JRS-26/35-1		50~150mm²		50~120mm²
		CN-JRS-26/35-2		185~300mm²		150~240mm²
		CN-JRS-26/35-3		400~500mm²		300~400mm²
		CN-JRS-26/35-4		630~800mm²		500~800mm²



Product keywords:

cable accessory, power cable accessory, XLPE cable accessory, low voltage cable accessory, LV cable accessory,

indoor cable accessory, indoor power cable accessory, indoor XLPE cable accessory, indoor low voltage cable accessory, indoor LV cable accessory,





indoor heat shrinkable cable terminals, indoor heat shrinkable power cable terminals, indoor heat shrinkable XLPE cable terminals, indoor heat shrinkable low voltage cable terminals, indoor heat shrinkable LV cable terminals,



indoor heat shrinkable low voltage cable termination kits, indoor heat shrinkable LV cable termination kits, indoor heat shrinkable cable termination kits, indoor heat shrinkable power cable t termination kits, indoor heat shrinkable XLPE cable termination kits, indoor heat shrinkable low voltage cable termination kits, indoor heat shrinkable LV cable termination kits,



indoor heat shrinkable low voltage cable termination, indoor heat shrinkable LV cable termination, indoor heat shrinkable cable termination, indoor heat shrinkable power cable t termination, indoor heat shrinkable XLPE cable termination, indoor heat shrinkable low voltage cable termination, indoor heat shrinkable LV cable termination,



indoor heat shrinkable low voltage cable joints, indoor heat shrinkable LV cable joints, indoor heat shrinkable cable joints, indoor heat shrinkable power cable joints n, indoor heat shrinkable XLPE cable joints, indoor heat shrinkable low voltage cable joints, indoor heat shrinkable LV cable joints,



indoor heat shrinkable low voltage cable joint kits, indoor heat shrinkable LV cable joint kits, indoor heat shrinkable cable joint kits, indoor heat shrinkable power cable joint kits n, indoor heat shrinkable XLPE cable joint kits, indoor heat shrinkable low voltage cable joint kits, indoor heat shrinkable LV cable joint kits,



 indoor heat shrinkable low voltage cable straight through joints, indoor heat shrinkable LV cable straight through joints, indoor heat shrinkable cable straight through joints, indoor heat shrinkable power cable straight through joints n, indoor heat shrinkable XLPE cable straight through joints, indoor heat shrinkable low voltage cable straight through joints, indoor heat shrinkable LV cable straight through joints,
