High filling accuracy anti-dropping type edible oil filling machine

No

Components

Material / Short List

1

Products Touching Parts

Stainless Steel 304 as the standard,

Stainless Steel 316,316L at the Buyer’s option

2

Structure / Support

Carbon Steel or High Class Aluminum

3

Main Surface

Stainless Steel 304

4

Programmable Logic Controller

Delta, Siemens, Mitsubishi, Panosonic

5

Touch Screen

Weinview, Siemens,Delta,Kinco, Panosonic

6

Stepper/Servo Motor

Teco, Delta, Panosonic,Leadshine

7

Frequency Convertor

Delta,Schneider,Leadshine

8

Key Electric Components

Schneider,Chint, Ls, Ark

9

Key Protection & Relay

Schneider

10

Cylinder, Filter

Airtac , SMC

11

Photocell Sensor

Autonics , Keyence,Leuze, Panosonic,Datalogic

12

Vacuum Sucker

Airtac, Sunx

13

Temperature Controller

Omoron

No

Document

Code

Description

1

Products Selection Guide

SG

To select or customize the suitable products for the clients upon the feedback of Selection Guide, which include project background, parameters and other client’s requirement

2

Products Profile

PP

To enable the clients understand the overview of the products, Covers sections of Basic Features, Application, Construction, Typical Products, Approvals, and Optional Features

3

Installation Instruction

IN

To explain the step of installation of the equipment, and include commissioning instruction as well

4

User Manual

UM

To cover the content of Operation & Maintenance and Trouble Shooting

No

Issue

Description

1

Type of Oil

To specify the type of oil , like vegetable oil, palm oil , bean oil, peanuts oil , or other plant oil etc.

2

Type of container to be filled

1)      Bottle, Stand up pouch, Pot and the what is the packing materials , like PE, Laminate heat sealable film, plastic ,glass etc.

2)      Size of container, Diameter/ Width, Height

3)      Sealing or capping requirement, if capping need to specify the type and dimension of cap

4)      Labeling Requirement

3

Range of Filling

To specify how many liters to be filled in one container, it is fixed volume or frequently change the volume of filling, if yes, need to specify the range.

4

Filling Accuracy

To specify the filling accuracy requirement for regulation compliance or filling materials cost saving

5

Filling Speed

To specify bottle ( bags) per hours.

6

Automation Requirement

1)      Filling Material Loading , Products un-loading

2)      Container sorting and feeding

3)      Boxing Requirement

7

Other Special Requirement

To be advised
