Servo Motor Driven Side Sealing Bag Making Machine for Chicken bag

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Machine Type:	Sealing Machine	Bag Type:	Other, SIDE SEAL BAG, SHOPPING BAG	Material:	Plastic
Computerized:	Yes	Place of Origin:	Shanghai, China	Brand Name:	SINGSIANG
Model Number:	SHSS-A

Product Description

Specifications

Side sealing machine
High stability Low maintenance Sealing and Cutting neat
More optional device
60 inch width is available

Side sealing machine especial for chicken bag

High stability!

Low maintenance!

Sealing & Cutting Neat & Clear!

More optional device, also applicable for making T-shirt bag and Bottom Sealing bag!

Super Wide up to 60 inch width is available!

SHSS SERIES is applicable for general side sealing plastic bag, such as OPP bags, hanging Bags, zipper bags, carry bags, book cover, T-Shirt bags,shopping bag etc.SHSS SERIES is also available for special design.

Optional Accessories:

Round hole punching device.	Bag dividing device.
Butterfly hole punching device.	Automatic hot melt coater.
Automatic product outfeed conveyor.	Ultrasonic longitudinal sealing device.
Edge positioning controller (EPC).	Zipper device
Upper and lower line heating device.	Hem sealing device
Solid edge device	T-shirt bag making device

Special Features:
Servo Motor Driven, Efficient mechanical structure		Automatically stop when running out of film
Fully Automatic, Large control panel Screen , Easy to read, User Friendly		Automatically stop when film feeding blocks or bags jam
Efficient output, less man power required		Automatically stop when The temperature not reaching setting.
Digital setup, accurate registration, less waste		Automatically stop when the bags become super-imposed or overlapped
Pleasant Cutting and Sealing, with high firmness
Cutting Blade is very lasting, and easy for adjustment
Imported high speed conveyor belt for long service life.
Convenient to change for various bag shapes.
Various unwinder and rewinder to meet requirements.
Ruggedly constructed for maximum stability during high speed operations.

SPECIFICATION:
MODEL	MAX. WIDTH	MAX. LENGTH	CONVERTING THICKNESS	ACCURACY LENGTH	SPEED (PCS/MIN)	SERVO MOTOR	HEATER	POWER REQUIRED	DIAMENSION L * W * H (CM)	MACHINE WEIGHT
SHSS-30	750 mm	1200 mm	0.015 - 0.08 mm	± 1mm	Max. 210	1.5 KW	2.0 KW	2.2 KW	410142171	1050 KG
SHSS-36	890 mm	1200 mm	0.015 - 0.08 mm	± 1mm	Max. 180	2.0 KW	2.5 KW	2.5 KW	410157171	1150 KG
SHSS-42	1050 mm	1200 mm	0.015 - 0.2 mm	± 2mm	Max. 150	3.0 KW	3.5 KW	3.2 KW	450172171	1300 KG
SHSS-50	1250 mm	1800 mm	0.015 - 0.2 mm	± 2mm	Max. 120	4.4 KW	4.0 KW	4.0 KW	450193171	1450 KG
SHSS-60	1500 mm	1800 mm	0.015 - 0.2 mm	± 2mm	Max. 100	4.4 KW	5.5 KW	5.5 KW	450219171	1650 KG
