Home > Products > Wiring Accessories > PVC Coated SS316 Stainless Steel L Type Insulation Wire Ties
PVC Coated SS316 Stainless Steel L Type Insulation Wire Ties
- 30000000 Piece / Pieces per Month
- Ningbo or Shanghai
- T/T Credit Card
You May Like
-
Pvc Coated Stainless Steel L Type Cable Ties For Ship-Building
-
SS316L Stainless Steel Cable Ties For extra corrosive environments
-
Self-locking Stainless Steel Cables Management
-
Stainless Steel Cable Ties- Ball-Lock Polyester Coated Ties
-
Black Band Coated with Metallic Buckle Self-locking Stainless Steel Cable Ties
-
metal strapping in Plastic box
Product Details
| Place of Origin | China | Brand Name | JIONG | |
| Model Number | JHLN | Type | Other, manul-locking | |
| Material | Steel |
Product Description
wing lock stainless steel cable ties/ Stainless Steel Tie Wing Lock
Product Feature
Uncoated version, for high temperature applications
Applications:
Ideal for petrochemical, traffic signal facilities, oil and gas transmission, telecommunication, power station, mining, car/plane/ship-building, offshore and any other aggressive environments.
Ideal for bundling in application, where high vibration is a concern.
Technical Information
Material: Stainless Steel Grade 304 or 316
Working Temp.: -80 to 538
Description: Entirely Metallic
Flammability: Fireproof
Other Properties: UV-resistant.
Naked Stainless Steel Tie Wing Lock
| JIONG NO. | Approx. Length mm(inch) | Approx. width mm(inch) | Thickness | Max,bundle dia.mm(inch) | Min,loop tensile strength N(lbs) | Pcs/bag |
| JHLN-12 x 200 | 200(7.87) | 12(0.47) | 0.3 | 50(1.97) | 1200(270) | 100 |
| JHLN-12 x 250 | 250(9.84) | 0.3 | 63(2.48) | 100 | ||
| JHLN-12 x 300 | 300(11.8) | 0.3 | 76(2.99) | 100 | ||
| JHLN-12 x 350 | 350(13.78) | 0.3 | 89(3.5) | 100 | ||
| JHLN-12 x 400 | 400(15.75) | 0.3 | 102(4.02) | 100 | ||
| JHLN-12 x 450 | 450(17.72) | 0.3 | 115(4.53) | 100 | ||
| JHLN-12 x 500 | 500(19.69) | 0.3 | 128(5.04) | 100 | ||
| JHLN-12 x 550 | 550(21.65) | 0.3 | 141(5.55) | 100 | ||
| JHLN-15 x 250 | 250(9.84) | 15(0.59) | 0.3 | 63(2.48) | 1500(337) | 100 |
| JHLN-15 x 300 | 300(11.8) | 0.3 | 76(2.99) | 100 | ||
| JHLN-15 x 350 | 350(13.78) | 0.3 | 89(3.5) | 100 | ||
| JHLN-15 x 400 | 400(15.75) | 0.3 | 102(4.02) | 100 | ||
| JHLN-15 x 450 | 450(17.72) | 0.3 | 115(4.53) | 100 | ||
| JHLN-15 x 500 | 500(19.69) | 0.3 | 128(5.04) | 100 | ||
| JHLN-15 x 600 | 600(23.62) | 0.3 | 154(6.06) | 100 | ||
| JHLN-15 x 700 | 700(27.56) | 0.3 | 180(7.09) | 100 | ||
| JHLN-15 x 750 | 750(29.53) | 0.3 | `191(7.52) | 100 | ||
| JHLN-15 x 800 | 800(31.5) | 0.3 | 193(7.59) | 100 | ||
| JHLN-15 x 1000 | 1000(39.37) | 0.3 | 206(8.11) | 100 | ||
| JHLN-19 x 300 | 300(11.8) | 19(0.75) | 0.4 | 76(2.99) | 2000(440) | 100 |
| JHLN-19 x 400 | 400(15.75) | 0.4 | 102(4.02) | 100 | ||
| JHLN-19 x 500 | 500(19.69) | 0.4 | 141(5.55) | 100 | ||
| JHLN-19 x 600 | 600(23.62) | 0.4 | 154(6.06) | 100 | ||
| JHLN-19 x 700 | 700(27.56) | 0.4 | 180(7.09) | 100 | ||
| JHLN-19 x 800 | 800(31.5) | 0.4 | 193(7.59) | 100 | ||
| JHLN-19 x 900 | 900(36) | 0.4 | 200(8) | 100 | ||
| JHLN-19 x 1000 | 1000(39.37) | 0.4 | 206(8.11) | 100 |
Epoxy Coated Wing Lock Stainless Steel Ties
PVC Coated Wing Lock Stainless Steel Ties
Why Chose Us?
1.We are factory,the price are competitive.
2.Good quality,the goods are passed UL,ROHS,CE,SGS,CCS ect. They have been exported to many countries and enjoy good popularity.
3.Quickly delivery,we have automatic production line,so the production is much quicker. Keep smooth delivery on time.
4.Perfect package according your demand
5.We have design/technology team and can make new products according your demand.
Trade team of products
1.Payment:T/T,L/C,D/A,D/P ,Western Union,Paypal etc.
2.Supply Ability:20ft Container/Month
3.OEM: accept
4.Delivery: •By Courier: 1-2 Working days by special offer
•By Air: 4-7 Working days at appointed airport
•By Sea:20-25 Working days at appointed port
Package of products
•Common Packing:100Pcs+Polybag+Label+Export Carton
•Customized Packing:Header card packing,Blister with card packing,Double Blister packing,Canister packing,other packing can be supplied according customers requirement.
Services
Excellent service and first-class after-sale service
•Provide professional sale person to communicate with you before the order
•Provide optimum system solution based on each client’s export
•Provide strict check for each part,each process before export.
•Provide post-sale service,including installation,technical guide and training.
If you are interested in our products, please contact with us. Thank you.
Tel: 86-0577-61785306
Contact Person: Daisy Zheng
MOB: 86-13506671646
Skype: daisy-zwt
QQ:3201757668
