Acemax KI DVB S2 hybird ip set top box Android OTT Box + DVB Hybrid quad core Amlogic S805

Acemax KI DVB S2 hybird ip set top box Android OTT Box + DVB Hybrid quad core Amlogic S805

Amlogic S805 Quad Core Android TV Box and with DVB-S2 HD, CCCAM, NEWCAMD, BISS, Smart S2 Set Top Box,PVR,Timeshift,1080 HD,WIFI Build in, ARM Cortex A5, XBMC Kodi

The Google Smart Android 4.4 TV box with hardware HD encoding, the Smart STB build in DVB-S2 HD TV tuner for receiving DVB-S2 HD free to air digital TV, and with PVR function also,Timeshift, XBMC Preinstalled

ARM Cortex™-A5 x 4 processor provides unprecedented levels of performance and power efficiency.

Embedded high-performance Open GL 3D graphics processor, provides super anti-aliasing 3D Game processing ability

Build in TV tuner for free to air digital TV receiving HD DVB-S2 is ready Support Live TV PVR.

Built-in Wi-Fi wireless module and 10M/100M cable network LAN port, file share via LAN/WLAN to PC

Support for file upload / download fields in the Browser application

Support for installing applications to the expandable memory

Support Microsoft Play-Ready / DRM 10 •Support 2D / 3D User Interface

Model: k1 DVB-S2 HD

Android 4.4 Google Smart TV box, IP box

Android DVB-S2 HD Set Top Box

PVR,Timeshift

XBMC Preinstalled

with CCCAM functions

Supporting biss

supporting newcamd

Basic Feature

System: Android 4.4 Kitkat

CPU: AMLOGIC  S805 Quad Core

DDR3:1GB

Nand Flash:8GB

Video Decoder

 Profile level: MPEG-1/2/4,VC-1,H.264

 Video resolution: Upto 1920x1080 pixels

 Aspect Ratio: 4:3, 16:9, Letterbox

Network:

 Ethernet

 WiFi: 802.11b/n/g protoco

Power

 Input Voltage range: DC 12V/1A

 Power Consumption: max 5W

 Stand-by mode: max 1w

File Format:

Video Format: MKV/AVI/MP4/MPG/ISO/IFO/MOV/XVID/M2TS/TS/WMV/VOB/DAT/RM/RMVB

Audio Format: MPEG/MP3/WMA/WAV/AAC/DD+/DTS

Picture format: JPEG/BMP/PNG/GIF

Tuner

Tuner
 Front End: DVB-S2
Input Frequency Range:
950~2150MHz
RF input Signal Level:
-65 ~ -20 Dbm

Demodulator

QPSK/8PSK

Connectors

Antenna Input: IEC Female

RF Loop through: IEC Male

CVBS, L, R, COAXIAL

RJ45: Ethernet

HDMI: 1.4 version

USB:USB2.0X4

TF card Slot

Accessories:

RCU without battery

hdmi calble

user manual

Power Adapter

2.4G Air/Fly Mouse with QWERTY Keyboard Optional (Suggested)
