thermostatic expansion valve TRFE
- 500 Piece / Pieces per Month
- Shanghai
- T/T
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Gate | |
| Pressure | Medium Pressure | Power | Other, heat | |
| Material | Brass | Temperature of Media | Normal Temperature | |
| Media | Gas | Port Size | 16MM, 5/8In | |
| Place of Origin | Shanghai, China | Model Number | TRFE | |
| Brand Name | STF thermostatic expansion valve |
Product Description
Specifications
TCLE/TRFE series are take-apart valves applicable to freezing ,refrigeration and air conditioning plant.
Characteristics
l Interchangeable orifice assembly ,easier stocking ,easy
capacity matching ,better service.
l Stable superheat setting.
l Can be supplied with MOP(Max operating pressure).
l Input and output type and size according to customer’s
requirement.
l Suitable for R22, R134a, R407C, R404A/R507.
l If you have special requirement , please cantact STF.
| R134a | R22 | R407c | R404A/R507 | ||||||||
| (Model) | Nominal capacity(KW) | (Model) | Nominal capacity(KW) | (Model) | Nominal capacity(KW) | (Model) | Nominal capacity(KW) | ||||
| TRFE | 11M | 38.72 | TRFE | 14H | 49.28 | TRFE | 14N | 47.93 | TRFE | 10S | 35.2 |
| TRFE | 13M | 45.76 | TRFE | 18H | 63.36 | TRFE | 18N | 61.59 | TRFE | 12S | 42.24 |
| TRFE | 16M | 56.32 | TRFE | 22H | 77.44 | TRFE | 22N | 75.88 | TRFE | 15S | 52.8 |
| TRFE | 19M | 66.36 | TRFE | 26H | 91.52 | TRFE | 26N | 90.79 | TRFE | 18S | 63.36 |
| TRFE | 25M | 84.48 | TRFE | 35H | 123.2 | TRFE | 35N | 121.9 | TRFE | 25S | 88 |
| TRFE | 31M | 105.6 | TRFE | 45H | 158.4 | TRFE | 45N | 156.78 | TRFE | 32S | 112.64 |
| TRFE | 45M | 147.84 | TRFE | 55H | 193.6 | TRFE | 55N | 191.41 | TRFE | 38S | 133.76 |
| TRFE | 55M | 193.6 | TRFE | 75H | 264 | TRFE | 75N | 262.5 | TRFE | 52S | 183.04 |
| TRFE | 68M | 228.8 | TRFE | 100H | 352 | TRFE | 100N | 350.17 | TRFE | 70S | 246.4 |
| TRFE | 80M | 280.6 | TRFE | 120H | 420.7 | TRFE | 120N | 416.7 | TRFE | 84S | 295.7 |
| Form of connection | Connection size | A | B | C | D | E | F | G | H | I | Capillary length | |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | ||||
| Inlet | Outlet | 1.5m or 3m | ||||||||||
| Straight-thru | ∅22 ODF or 7/8 | ∅22 ODF or 7/8 | 138 | 55 | 49 | 44 | 90 | 122 | ∅13 | 65 | 50 | |
| ∅28.5 ODM or 1-1/8 | ∅28.5 ODM or 1-1/8 | |||||||||||
| Angle | ∅22 ODF or 7/8 | ∅22 ODF or 7/8 | 138 | 55 | 49 | 44 | 90 | 122 | ∅13 | 65 | 50 | |
| ∅28.5 ODM or 1-1/8 | ∅28.5 ODM or 1-1/8 | |||||||||||
| Flange | ∅33X∅35 | ∅33X∅35 | 123 | 115 | 85 | 111 | ∅35 | 122 | ∅13 | -- | -- |
Factory setting :superheat 3.5K, static superheat adjusting range is between 2~8K.
Turn adjusting stem anticlockwise one round ,reduces superheat 0.3K.
Note :If you have special requirement ,please contact STF.
