optical fiber fusion splicer

Applicable fibers

SM MM DS NZDS

Fiber diameter

Cladding diameter:80-150μm

Fiber count

Single

Fiber cleaved length

8-16mm (Coating diameter:250μm)

Actual average splice loss

0.02dB(SM),0.01dB(MM),0.04dB(DS),0.04dB(NZDS)

Typical splicing time

Typical 9 sec (standard SM fiber)

Return loss

>60dB

Splicing mode

Auto Calibrate Normal Special

Fiber aligning method

Meticulous,Core,Clad,Manual

Splicing program

53 (templet), 40(user)

Tube heating program

9 (templet),24(user)

Tube typical heating time

Typical 30 sec

Protection sleeve length

60mm, 40mm

Storage of splice result

4000 results, 20 parameter per result

Fiber image magnification

200X (X or Y view),50X (X and Y view)

Battery capacity

Typical 300 cycles (splice/tube heaty)

Monitor

3.5 inch TFT color LCD monitor

Tension test

2N

Electrode life

2500

Terminal

USB

Power supply

AC 100-240V with AC adapter

Inner Li-battery (5200mAh)

Operating condition

0-5000m above sea level, -10-50°

Max wind velocity of 15m/s

Dimension

125mm(L)×105mm(W)×113mm(H)

Weight

1.55Kg including battery

Function

KL-280G

KL-280

KL-300T

KL-500

Display fiber cleaved angle

-

-

*

*

Display fiber offset angle

-

-

*

*

Display core offset

-

-

*

*

Display clad offset

-

-

*

*

Splicing mode (Auto, Calibrate ,Normal ,Special)

*

-

*

*

Fiber aligning method (Core,Clad,Manual)

*

-

*

*

Arc strength automatic adjustment

*

-

*

*

Image turn over

-

*

*

*

Fiber angle limit

-

-

*

*

Display inside temperature

-

-

*

*

Display ambient temperature

-

-

*

*

Display heater temperature

-

-

*

*

Display air pressure

-

-

*

*

Display battery voltage

-

-

*

*

Taper splice

-

-

*

*

Sleep

-

-

*

*

Auto shut down

-

-

*

*

Software upgrade via USB interface

*

-

*

*
