Mechanical Dividing Head
- 10 Unit / Units per Month
- shanghai
You May Like
Product Details
| Place of Origin | China | Brand Name | THL | |
| Model Number | F2/F2-6 |
Product Description
Specifications
Mechanical Dividing Head is the most optimum in use for milling machines,grinding machines,drilling machines and planer etc.Type F2,F2-6 super spacer is designed for using and indexing in both horizontal and vertical position.It is the most optimum in use for milling machines,grinding machines,drilling machines and planer etc. The divisions in 2,3,4,6,8,12,24 are permitted any desired angular indexing can be performed too by using a graduated ring on the spindle and a verner.
Items | Units | F2 | F2-6 |
Center hight | mm | 149.25 | 130 |
Center diameter of the spindle | mm | 119.774 | 80 |
Divisions | mm | 2,3,4,6,8,12,24 | |
Height between external centering diameter of the spindle to the base(in vertical position ) | mm | 96 | 89.5 |
Locating diameter of the spindle | mm | 212 | 170 |
Width of the locating key | mm | 16 | |
Matched chuck |
| K31210A | K31167 |
24 divisions individual error |
| 25'' | |
Net weight | kg | 52 | 33 |
Gross weight | kg | 60 | 39 |
Case dimesions | mm | 405*370*345 | 372*340*304 |
