double wall vertical diesel storage tank

Specifications

Single Wall Storage Tank, Double Wall Storage Tank, Double Skin Storage Tank, Bunded Storage Tank, Diesel Oil Storage Tank

DOUBLE WALL FUEL STORAGE TANKS

Double Wall aboveground Tanks



General Specifications:



-Internal and external tanks manufactured in carbon steel.

-Between the 2 walls there is an interstitial space that possibility the leak detection.

-Tanks manufactured according to European Norms or API-650

-Capacity range from 1.000 to 120.000 Litres (250 to 30.000 US Gallons).

-Tank Diameters: 900, 1.250, 1.500, 1.900, 2.200, 2.500 and 3.000 mm.

-High quality welds by submerged arc SAW.

-The carbon steel used (according the EN 10025-2) of high mechanical strength and deformation capacity

-Supports cradles and manhole access ladders are incorporated.



Superficial finish

-External: Sandblasted SA 2-1/2 and Coating with one hand of zinc silicate primer and other hand of Polyurethane, RAL9010 White colour, to a minimum thickness of 90 microns.

-Internal: Clean.



Leak detection:

-Monitored detection by liquid and alarm



Possibility of changes:

-Custom works ready for turnkey.

-110% bund.

-Single wall tank.

-Overfill chamber

-Internal heat exchanger

-Many kind of diesel or petrol dispensers

-Special manhole connections and additional manholes.

-Special ladders and platforms.

-Multi-compartment.

-Special diameters and lengths.

-Containerised tanks.

-Different possibilities of coatings and linings.



CONTAINERISED TANKS AVAIBLE
