submersible water pump with stirring cutting system
- 10000 Unit / Units per Month
- NINGBO
- T/T
You May Like
-
New design sewage submersible pump ,submersible sewage cutter pump
-
cutting submersible pump with grinder system
-
Professional Manufacturer of Sewage Pump Stainless Steel Centrifugal Submersible Pump
-
Cost-effective VP220F model float switch submersible sewage pump,plastic sewage pump
-
Best Selling VP370F plastic submersible pump,electrical submersible pump,sewage water pump
Quality Choice
-
Top quality sewage pump submersible water pump
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Unipome | |
| Model Number | WQCS | Theory | Centrifugal Pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other, electric | Pressure | Low Pressure | |
| Application | Sewage |
Product Description
Specifications
1,submersible sewage pump2,made of hard alloy and reliable protection device
3,stainless steel impeller with cutter
submersible sewage pump with stirring cutting system
Specifications
submersible sewage pumps
1, Power cable: standard cord is 10m
2, Liquid Temperature: 40°c continuous
3, Motor: class B insulation, IP68 protection
4, Single Phase: Built-in thermal protector
5, Accessories: Float switch is available
Materials
Pump casing: Plastic
Impeller: stainless steel vortex
Double-sided Mechanical Seal: Burna-N elastomers
Motor side Mechanical Seal:carbon VS silicon carbide
Pump side mechanical seal: silicon carbide VS silicon carbide
Shaft:45# steel or stainless steel
Bearing:SKF/NTN/China
LIMITS OF USE
8Maximum operating depth 5m below waterlevel
8Maximum fluid temperature 40°C
8PH value in water :4-10
8 Maximum Passage for suspended solids: 35mm
8 Protection:IP68
General Characteristics
* Impeller with a grinder system
* Grinder system contain a revolving cutter and a plate withholes, sharpened edges that fine-chops filaments, preventing fouling of the impeller.
Model Analysis
Performance Table
Certificate
