Home > Products > Magnetic level gauge > UHZ517 Corrosion Proof Magnetic Liquid Level Meter
UHZ517 Corrosion Proof Magnetic Liquid Level Meter
Negotiable
/ Set
1 Set(Min.Order)
- 3000 Set / Sets per Month
- Shanghai China
- T/T Credit Card PayPal
You May Like
-
UHZ 517C14 float ball water level for liquid gas max 100 centigrade 300lb from water meter manufacturer in China
-
UHZ 517C17 corrosion proof magnetic level gauge with UPVC fittings from water meter manufacturer in china
-
UHZ 517C12B float type level sensor for measuing tool high temperature 450 centigrade high pressure PN6.4 400lb side-mount
-
UHZ 517C10 fuel tank gauge for fuel level meter max 200 centigrade 150lb side mount
-
UHZ 517C11 fuel tank gauge for survey level control high temperature max 450 centigrade
-
UHZ 517C12A fuel tank gauge for float ball water level 450 centigrade 300lb
Product Details
| Place of Origin | Shanghai, China | Brand Name | XINGSHEN | |
| Model Number | UHZ517C19 |
Product Description
Specifications
1. PPR lined Stainless Steel body2. For hydrochloric acid, alkaline liquids and many organic solvents measure
It is for level measurements of hydrochloric acid, alkaline liquids and many organic solvents (especially active solvents), but it is not for measuring levels of concentrate nitric acid, chromium acid mixture, chloride solvent, aliphatic series and aromatic hydrogen etc.
Technique Parameter
Measure Range: | 300~6000mm (center distance) or on request. |
Nominal Pressure: | PN1.0MPa |
Working Pressure: | ≤0.75MPa |
Working Temperature | -20°C~80°C |
Medium Density | 600~2000kg/m³ |
Chamber(bypass tube) | Φ76×3mm |
Process Connection | Factory Standard: DN25 PN1.0MPa; Or on request |
Chamber/Flange/ Wetted Material | Chamber:304SS Flange:304ss CS Wetted material: PPR |
Magnetic Float | Its size depends on liquid density Material: PPR
|
Optional Items | 1. Tri-magnet level switch 2. Drain valves(PPR ball valve) 3. Level Transmitter 4. Magnetostrictive level transmitter |
