RF2030F Guided Wave Radar Level Transmitter for High Temperature High Pressure Digital Water Level Indicator

Specifications

1. high temperature pressure
2. for boiler steam drum
3. high accuracy
4. guided wave probe not affected by condensed water



TYPICAL APPLICATIONS :



1.    Various industrial drum boilers

2.    High or low pressure vessels

3.    Waste heat boilers

4.    Converting  kilns

5.    High pressure heat accumulators

6.    And other high temperature high pressure steam applications

















TECHNICAL  PARAMETER :



Output signal:  two wire 4~20mA, compatible with HART communication



Power supply: 11~28.6VDC (Intrinsically-safe);

                            11~36VDC (explosion-proof)



Safety class : Intrinsically-safe: ExiaIICT2-CT6

                          Explosion-proof: ExdIICT2-CT6



Nominal pressure: high pressure ≤32Mpa

Medium temperature:  high temperature <520°C

Probe length: coax / rob ≤ 6.1m

Load resistance: ≤650Ω

Electric interface: defalult M20×1.5, or on request;

Accuracy: coaxial type 0.1%FS

Repetition: ≤ 2mm

Temperature influence: probe length change (-0.02%) as temperature change.

Data updated: 30ms

Damping time: 0~32s adjustable

Fault-diagnosis, alarm: 3.6mA,22mA,HOLD

User interface: 3 key +LCD display

Ambient temperature : -40~+60°C  RH: 0~99%

Housing material: Al+ spray plastics (Cu <0.25% of Al)

Protection: IP67



SPECIFICATION LIST :
