RS485 supported elevator control card reader for elevator control KO-3201

Specifications

elevator control card reader
1,support 32 output
2, 20,000 card capacity
3, 60,000 log capacity
4, RS485

RS485 supported elevator control card reader for elevator control KO-3201





Elevator controller Specifications:



Board Size: 218mm × 136mm × 32mm

Motherboard Color: dark blue (standard board)

Motherboard Weight: about 450 grams

Case Size: 285mm × 240mm × 82mm

Chassis Color: Black

Chassis Weight: Approximately 1,400 g (large box 2400 g)



Working temperature: <60 °C

Humidity: 10% ~ 95% R.H

Working voltage: DC 12V

Operating Current: <100mA

Rated Power: ≤ 5W

Power protection: 10 years



Interface Configuration

Card Reader: 2 (WG WG reader and other means of communication signal input devices)

Fire Inputs: 1

Floor buttons: 32

Limit Inputs: 1

Control output: 32 (dry contact output, no voltage)



Performance Parameters

Card Capacity: 20,000

Record stock: 60,000

Alarm Capacity: 60,000

Communication: 485

Communication distance: 1200 m (actual project application control in the 800 meters or less is appropriate)

Reader Communication: wiegand (Wiegand) mode

Communication distance: 100 meters

Open the door: Card, password, card + password, dual card, the first card to open the door, software, fire alarm, button, timer



Elevator controller Pictures:
