New design hot press hydraulic pressure station piston cylinder with high quality

FOB Price

USD $1 - $2 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Hot Press Machine
Place of Origin	Shandong, China	Brand Name	RLK
Model Number	RLK21-4'*8'/40-15	Voltage	380V
Power(W)	14.1kw	Dimension(LWH)	356013704240mm
Weight	32000kg	Certification	CE ISO9001
Warranty	3 years	After-sales Service Provided	Engineers available to service machinery overseas

New design hot press hydraulic pressure station piston cylinder with high quality

Model	hot press hydraulic pressure station piston cylinder
Frame style	Combination frame
Quantity and Diameter of Cylinder	2 units Φ320mm
Nominal Pressure	400Tons
Quantity of layers	15 layers
Separation between layers	70mm
Stroke of Cylinder	1050mm
No-load closing time	About 15s
Hydraulic system control method	Manually/Automatic controlled
Hydraulic system pressure	25MPa
Main motor	11KW
Pressurized motor	7.5KW
Main pump	Shanghai Aviation 250 pump
Pressurized pump	10ml/rev plunger pump
Heating platen(working table size)	2700137042mm
Heating Meduim in the heating platen	steam or heat transfer oils
main frame steel plate thickness	35,22,12mm
Upper, Bottom crossbeam	900,800,400mm
Movable crossbeam	27001370400mm
Dimensions of Main frame	356013704240mm
Weight	32000KG
Production Capacity	about 30 sheets of plywood in one hour
Upper&Bottom Crossbeam	800mm 900mm

Welcome your inquiry and visit about New design hot press hydraulic pressure station piston cylinder with high quality
