Home > Products > Fuel Injection Pump Test Bench > Hot Sell HY-NK Fuel Pump Test Bench,Test Inline Pumpand Distribution Pump
Hot Sell HY-NK Fuel Pump Test Bench,Test Inline Pumpand Distribution Pump
- 10 Set / Sets per Month
- Qingdao
- Credit Card PayPal
-
Transfer Pump Test Bench.
-
hot product , HY-NK Feul Injection Pump Test Bench
-
professional service HY-WKD Bosch fuel injection pump test bench
-
compensatory device of distributing pump HY-NK Feul Injector Test Bench
-
HY-WKD Fuel injection pump test equipment measuring the travel of gear lever
-
HY-WK fuel injection pump test instrument( measuring the pressure of pump chamber
Product Details
Type: | Engine Analyzer | Voltage: | 220V/380V | Power: | 11kw |
Certification: | ISO9001:2008 | Applicable Models: | all cars | Place of Origin: | Shandong, China |
Brand Name: | Haiyu | Model Number: | HY-NK |
Packaging Details
wood package
Product Description
Specifications
fuel injector test benchCast iron operation platform
380V,three-phase four wire
HY-NK Fuel Injector Pump Test Bench
1. Adjusting each cylinder delivery at any speed.
2. Test point and interval angle of oil supply of injection pump.
3. Adjusting the performance of different speed regulator.
4. Checking of the sealing of injection pump.
5. Testing of oil return of distributing pump.
6. Checking of the pressure compensatory device of distributing pump.
7. Measuring of the internal pressure of distributor pump.
8. Measuring of the advance angle.
Power | 11kw/15kw |
Speed range | stepless frequency conversion, multi-gear speed overhead |
Speed range | 50-400 rpm or at will |
Debugged station | 12cylinders |
fuel supply | 0-0.4MPa(low pressure) 0-4MPa(high pressure) |
Filtering precision | 10um |
Fuel system | using radiator, air temperature display and automatic control |
overall dimension | 1800×750×1410(mm) |
net weight | 1000kg |
Company Profile
![](http://res.goldsupplier.com/3/1_701_11315_393_288.jpg)
Taian Haiyu Machinery Co., Ltd. is located at the foot of famous Mountain Tai in the north development zone of Taian City which is between spring town - Jinan and the hometown of Confucius - Qufu. We enjoy convenient transportation and Taian City is at the junction of Beijing-Fuzhou Highway and Beijing-Shanghai Highway.
Taian Haiyu Machinery Co., Ltd. is a modern technological company combing research, production, sale and service. We have a number of engineers working on designing and producing engine testing equipment and some sophisticated staff members specialized in computer software and hardware design. In recent years, we have cooperated with research institutions of universities. Our company succeeds in researching new series of HY injection pump test benches and injector test benches. Functions of the equipment have reached the internationally advanced level. We fully meet the needs of customers. Besides, we can also design particular testing benches according to customers' requests. In order to meet the requirements of lowering exhaust in diesel engine field and achieve European III standard, our company researches and develops common rail system test benches which have excellent functions and high accuracy. Our test benches have been widely used by internal engine industry and are exported to more than 30 countries and regions, including Asia, Africa and America.
Our company also has long-term cooperation with Guanghua Gas and imports SMC gas meter boxes, stainless steel meter boxes, cold plates and other metal products.
We adhere to the principle of "sincere cooperation" and warmly welcome customers from all over the world to visit us. We hope that you can work together with us for a beautiful future.
