Home > Products > CNC Winder > SRBC23-4 king spool winding machine
SRBC23-4 king spool winding machine
- 1000 Set / Sets per Month
- Xiaolan port
- Manufacturer provides straightly dedicated transformer coil 4 spindle coiling machine, automatic wire winding
- SRBC23-4 generator coil winding machine,guitar string winding machine
- SRBX23-4 Aluminum or Copper wire Transformer Winding machine
- 2016 super easy clapton coils winder hot sale in china
- SRBX23-4 copper and aluminum distribution coil winding machine
- 6-axis high speed automatic winding machine for sale
Product Details
Condition: | New | Application: | Relay Coil Winding Machine | Automatic Grade: | Automatic |
Production Capacity: | HIGH SPEED | Memory Capacity: | Good | Place of Origin: | Guangdong, China |
Brand Name: | SHILI | Model Number: | SRB23-4 | Voltage: | 220V |
Power(W): | 370W | Dimension(L*W*H): | 900*460*600mm | Weight: | 105kg |
Certification: | CE, high quality | Warranty: | One Year | After-sales Service Provided: | Overseas third-party support available |
Packaging Details
Plywood Box
Product Description
SRBC23-4 king spool winding machine
Descriptions of motor stator winding machinery
Spindle number | 4 |
Wire size range | 0.04-0.45mm |
Loop diameter | 80mm |
The max wire spacing | 9.99mm |
Winder width | 100mm |
Spindle pitch | 165mm |
Max speed | 6000 turn/min |
Spindle motor | Three-phase motor+Phase motor+AC Drivers |
Winder motor | Stepping motor |
Input power | 220V 50HZ/60HZ |
Machine size | 930×490×630mm |
Package size | 980×670×680mm |
Net weight | 85kg |
Gross weight | 100kg |
Application range:
EE transformer,EI transformer,Stepping motor,Relay,coil class,
auto ABS,Switch power transformer and special products.
1. Q: What is the power supply of the machine?
A: The standard power supply in china is 220v 50Hz. We also can customized accordingly.
2. Q: What information should the customer provide to get an accurate quotation from us?
A: The customer should provide the related technical requirements, drawings, pictures, etc .
3. Q: What is the payment term
A: The payment term is 100% T/T before shipment.
4. Q: What is the delivery time?
A: Normally the delivery time of the machine is 4-5 working days after receive payment.
5. Q: What is the warranty period of the machine?
A: The warranty period is one year.
6. Q: How to contact us?
A:Web:
Europe: | Germany,Czech Republic, |
Russia, | |
UK, France | |
Bulgaria, | |
Italy | |
North America: | USA, Canada, Mexico |
South America: | South America |
Australia | Australia |
Asia : | China, |
Singapore , Malaysia , Indonesia ,Vietnam, Tailand,Myanmar, | |
Bengal,India, Pakistan, | |
Turkey,Iran,Syria, ,UAE | |
Africa: | Egypt, Tunis, ,Algeria, Dominica, |
South Africa |
Company Profile
ZhongShan SHILI Winder Equipments CO., LTD
ZhongShan SHILI Winder Equipments CO., LTD. was founded in 1988, is a professional production winding equipment manufacturers in Zhongshan city, Guangdong Province. Which for more than 20 years, with the rapid development of enterprises and continued to expand, has become one of the largest professional manufacturers of domestic industry. Its products are sold not only throughout our country but also exported to USA,Germany,Europe,SouthAmerica,Australia,middle East,Asia,Southeast Asia and other countries and well received by the customer's favorite.
From inception, our company has been adhering to the "quality first, customer first" principle. Our company has advanced production equipment, experienced engineering device developers, strong professional production team and strict quality control system. Main products: Full-automatic winding machine, Wire twisting machine series, Computer controller winding machines series, EI lamination stacking machines series, Automatic tapping machines and other electronic equipment. We also can press the customer request to do product design and improvement.Quality assurance, reasonable prices, imposed on all products sold and after-sale service. We believe that through our efforts and pursuit, certainly achieve mutually beneficial win-win situation with our customers!
