Hydraulic Gearbox and System Test Stand And Test Rigs

FOB Price

USD $10,000 - $100,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Qingdao

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Shandong, China	Brand Name:	Highland	Model Number:	YST380/500/550
Power:	Hydraulic	Usage:	Universal Testing Machine

Packaging Details

According to the customers

Product Description

Specifications

1.Hydraulic comprehensive system test bench
2.Hydraulic Pump Test Stand
3.One year warranty

Hydraulic Cylinder Test Bench

Application Range:

YST Series Hydraulic testing table are used for checking and proofreading the products that include hydraulic pump,motor and valve,it also can conduct hydraulic system's breakdown diagnosis,these products are researched and produced by ourselves,so we could combine conduct according to customers'needs.

Product name	Cylinder test bench
Function	The cylinder test bench was developed for the cylinder used by excavators and rotary drill . This Cylinder test bench can do performance test for the various engineering fuel tank, the test parameters through sensors, data acquisition, display and industrial computer can bring about data acquisition, processing, printing characteristic curve, the performance curves and efficiency curves, test reporting and data management.
Test projects	No-load running back and forth test; Starting pressure test; Overload performance test; Impact test; Buffer leakage test; Leak test; Travel detection.
Performance parameters	Meet standards	GB/T 15622-2005
	Total power	55.5KW
	Range of test pressure	0~50MPa
	Range of flow rate	0~500L/min
	Range of rotational speed	0~3000r/min
	System temperature Control mode	Water cooling
Composition of the structure	Dynamic system, the hydraulic control system, the hydraulic oil filter temperature control system, the workpiece clamping device, the electrical control system, the data acquisition test system.
Application area	Various engineering cylinder

Company Profile

Ji'nan High Land Hydraulic Pump Co., Ltd.

Profile
Jinan High Land Hydraulic Pump Co., Ltd. , a professional high-tech enterprise that combines hydraulic design, manufacturing and maintenance. High Land owns strong ability of R & D, first-class scientific management elites and advanced equipment for manufacturing and testing.

Hydraulic Pump
Hydraulic Comprehensive Test Bench
Digital Hydraulic Test Bench
MYHT Portable Hydraulic Tester
Hydraulic Pump Parts

Service: On-site technical advisory for Hydraulic System
Maintenance: Hydraulic Pump or Motor imported or made in China

Jinan High Land Hydraulic Pump Co.,Ltd.
Address:N0.26, Beiyuan Street, Licheng District, Jinan
Tel: 0086-0531-88796130 88770136
Fax: 0086-0531-88796120
Technical Support: 13805406089
Post Code: 250100

Hydraulic Digital Test Bench
Maintenance and test equipment for testing Hydraulic Pump, Motor

Parameters:
Flow: 300-500L/Min
Pressure:35Mpa
Power: 75-250KW
Motive Power: Hydraulic Electromotor, Frequency Conversion Electromotor, Diesel Engine Drive

Portable Hydraulic Tester
MYHT Portable Hydraulic Tester is applicable for testing flow, pressure, temperature of hydraulic system of construction equipment. It widely absorbs advanced technical experience of international peers and has filled the blank of this field in China.

Potent No.: ZL 2005 2 0080054.X

Parameters:
Flow: 200---800L/Min.
Precision:1%
Pressure: 420bar
Temperature:150
Weight: 6.2-10.5kg

Product: Hydraulic Pump, Hydraulic Comprehensive Test Bench, Digital Hydraulic Test Bench, Portable Hydraulic Tester
Service: on-site technical advisory for hydraulic system, system reform, parts test

Maintenance: Hydraulic Piston Pump, Piston Motor, Valve, Sauer Pv20,90 series RexrothA10V, A4V, A11series, Kawasaki K3V, NV series, Komatsu, CAT
