High pitting rate fruit stone extracting eqipment

1.Introduction:

1.The fruits seed removing machine is automatic and can work continually.It save the time and high

cost of labor.

2.Reasonable structure and good design.

3.The machine is strong, durable. No need the workshop because of the small size.

4.High production efficiency and low power consumption. Denucleation rate is 98%.

2.Technical parameters of the fruit stone extracting equipment:

 3.Detail photoes of the fruit stone extracting equipment:

4.Differnt angle show of the fruit stone extracting equipment:

5.Spare part photoes:

6.Final product after pitting:

7.The operation photo from customer:

8.FAQ:

1.What kind of fruit you machine could process?

Our machine could remove the seed of  cherry,plum,apricot,date,olive,logan,apple,peach,hawthorn,

etc.

2.Could your pitting machine cut pitted fruits into halves?

Yes,our machine could cut the fruits into 2,4,6,8 halves after pitting.It's one machine with two function.

3.Is dry fruit available for your pitting machine?

Yes,our pitting machine could process dry and fresh fruits.

4.What information you need to manufacturer the most suitable machine for us?

We need to know the diameter of fruit and fruit kernel,length of the fruit.

5.Our fruits diameter is different,could your machine process it?

Yes,our pitting machine could process different diameter fruits,diameter range is 10-40mm,this could be customized according your fruit size.

6.What's the material of your machine?

Our pitting machine is made from full stainless steel,which is food standard.

7.Is our electricity available for your machine?

The electric motor of our machine could be customized according to your local electricity.

8.Do you have other delated machine?

Yes,we also have fruit washing machine,fruit grading machine and dicing machine if needed.

9.Features of the red date kernel pitting machine:

1.Use Special Punch pin to remove the fruit pit thoroughly.

2.The structure of machine is stable,durable,it is easy to change spare parts which is made of CNC.

3.Part in contact with fruits are stainless steel,it is easy to operate and wash.

4.Conveyor and cups is covered by special material to assure health requirements.

5.Newest continuous rotating feeding system and automatic control apparatus improve accuracy

precision.

10.Application scope of the red date kernel pitting machine:

Fruits pitting such as cherry,olive,red date,plum,apricot,peach,logan,waxberry,apple,pear,etc.

11.Working principle of the red date kernel pitting machine:

1.This pitting machine removes the hard stone from the fruits by two rollers (one has teeth on the

surface,and the other is made of rubber) which are kept a certain gap in between;by this way,the

fles of the fruit will be remained in state of pieces.

2.The gap between the two rollers is designed according to the feature and dimension of different

fruits;

3.The fruits fall down to the rollers from the former procedure and then are pressed to the gap by a

plate which moves up and down;

4.The two rollers rolls in opposite direction and most of the flesh is pressed to the gap of the teeth on

the roller meanwhile the stones(seed of the fruit) are pressed on the stretchy roller;the flesh between

the teeth on the roller will be then scratched out by a brush.

5.The stone still with some flesh on it will be backward washed by the stoner washer.

Note:We have the operation manual and working video of processing different fruits if needed.

Our unique service over others:

1.13 years experiences in this industry and professional technical team.

2.All material test before using to manufacture and quality assured.

3.Good feedback from clients after operating this machine.

4.5 year Gold Supplier and site checked by Alibaba.

5.Delivery on time and good after sale service(24 Hours).

 Our Gurranty:

1.Quality:Material adopt according to your choice and machine operation test before delivery.

2.Price:Factory direct sale service,most competitive over other companies.

3.Service:Always online technical service any time you need.

4.Packing:Standard export wooden box packing and marks at your request.

5.Delivery:On time delivery and most cost-effective routine for you.

Zhengzhou Dingsheng Machine Manufacturing Co.,Ltd was established in 2002.We have our own manufacturing factory.With the innovation and optimization of the industry,we are marketing our products into international market,and the export business is expanding rapidly.
