GPS Antenna navigator Amplifier 5M/16FT Car External Repeater Amplifier gps receive and transmit for Phone car
- 3000 Piece / Pieces per Month
- Shenzhen
- Credit Card
- Adhesive GPS Antenna with mmcx connector for car/auto
- Wholesale high quality mouse GPS Antenna with mmcx connector external 1575 GPS antenna
- Best selling 1575.42mhz gps antenna active external gps antenna for vechical nevigation
- Factory supply ODM mouse GPS Antenna with fakra connector for Glonass/Beidou/Galileo/GPS
- High Gain 29dBi navigation GPS Antenna for Glonass/Beidou/Galileo/GPS
- Wholesale Car Use High Gain 28dBi Active GPS Antenna for Glonass/Beidou/Galileo/GPS
Product Details
Place of Origin: | Guangdong, China | Brand Name: | YNX | Model Number: | YNX-GPS-Extenal GPS antenna |
Car Make: | Ordinary car | Frequence Range: | 1575.42mhz±1MHZ | Gain(dB): | 28dB±3dB |
Cable Length: | 3m |
Packaging Details
One product with one PE bag packaging of Extenal GPS antenna
Product Description
GPS Antenna navigator Amplifier 5M/16FT Car External Repeater Amplifier gps receive and transmit for Phone car
Any Qustion pls freely contact Skype:Yetnorson03 WhatsApp: +8613825271579
Welcome to Shenzhen Yetnorson technology Co., LTD.
Thank you for viewing this amazing ISO9001 Factory price GPS antenna for android tablet gps antenna for tablet gps antenna for laptop
The advantage of ISO9001 Factory price GPS antenna for android tablet gps antenna for tablet gps antenna for laptop
1,rich experience , proven technique
2,low price and high gain
3,wider frequency
1, Specifications of GPS Antenna navigator Amplifier 5M/16FT Car External Repeater Amplifier gps receive and transmit for Phone car
Antenna | Center Frequency | 1575.42±1MHz/1602mhz |
Band Width | CF±5MHz | |
Polarization | RHCP | |
Gain | 3dBic(Zenith) | |
V.S.W.R | <1.5 | |
Impendance | 50Ω | |
Axial Ratio | 3dB(max) | |
Dimension | 25*25*4mm | |
LNA | Gain | 26±2dB |
Noise Figure | <1.3 | |
Filter Insertion Loss | <3dB | |
Ex-band Attenuation | 12dB@CF+50MHz/16dB@CF-50MHz | |
Supply Voltage | 2.2~5V DC | |
Current Consumption | 10~26mA | |
V.S.W.R | <2.0 | |
Mechanical | Cable | RG174 |
Connector | SMA/MCX/FAKRA or others | |
Radome Material | ABS | |
Mounting Method | Magnet | |
Environmental | Operating Temperature | -40°C~+85°C |
Relative Humidity | Up to 95% | |
Ingress Protection | IP67 | |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours | |
Environmentally Friendly | ROHS Compliant |
2,The appearance of ISO9001 Factory price GPS antenna for android tablet gps antenna for tablet gps antenna for laptop
3,The Payment of ISO9001 Factory price GPS antenna for android tablet gps antenna for tablet gps antenna for laptop
We accept Paypal, T/T, Western Union, L/C and MoneyGram.
4,The Refund and ISO9001 Factory price GPS antenna for android tablet gps antenna for tablet gps antenna for laptop
1. We can guarantee the product quality within one years
2. If parts cannot work, we will return payment or replacement to you.
3. Any items must be returned in their original condition to qualify for a refund or replacement.
4. The buyer is responsible for all the shipping cost incurred
5 The Packaging and Shipping of ISO9001 Factory price GPS antenna for android tablet gps antenna for tablet gps antenna for laptop
1. The parts from us are sure to have quality warranty, and they are double tested before shipping.
2. The items can be sent within 7working day after the payment reaches us, except for mass process, we will confirm the delivery in advance.
3. We can send your order by UPS/DHL/TNT/EMS/FedEx. Please contact us directly and we will use your preferred ways.
4. Any import fees or charges are the buyer's responsibility. But we can help you reduce and avoid import taxes by declaring prices low, declaring the contents as "electronic accessories" or other items and shipping in simple packaging
6,Our Company
Shenzhen Yetnorson technology Co., LTD. as one of the emerging high-tech enterprise.Who is one of the leader who is engaged in the antenna products .custom service, R&D, design,Our main prooducts at GSM/GPS/CDMA/DVB-T/DMB-T/DAB-T/ISDB /PHS / 3 G / 4 G /5.8G, 2.4 GHz (WIFI, wireless local-area network (wlan)-/ 3.5 GHz wimax (5.8 GHz) / wireless spread spectrum communication series
7.Certificate
Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation.
Any Qustion pls freely contact Skype:Yetnorson03 WhatsApp: +8613825271579
Company Profile
Shenzhen Yetnorson Technology Co.,Ltd is one of professional antenna maker, which focus on GSM/CDMA/PHS/3G/4G antenna, 2.4GHz (wi-fi, wlan)/3.5GHz (wimax)/5.8GHz/wi-fi amplifier communication antenna serial(including: all direction, yagi antennas ,3G parabolic antennas, panel antenna, indoor antenna like : ceiling mount antenna, Wall Mount Antenna, desk antenna, double polar, rubber, bandwide, card mount serial antenna. We also provide DVB-T/DMB-T/CMMB moving digital TV antenna, low frenquency antenna: 315MHz/433MHz wi-fi digital /wi-fi control /wi-fi wrote water meter/electricity meter antenna, GPS guide antenna, communicate parts, connector and so on. At present, Shenzhen Yetnorson Technology Co.,Lth.has developed more than 100 styles of antenna, with wi-fi internet, wi-fi electronic control, wi-fi end, wi-fi public telephone, wi-fi digital pass, wi-fi Satilla position, wi-fi Radio broadcasting communication field.
We offer antennas with good quality and good price. And we are cooperating with several overseas clients from all over the world. Please support us. Thank you very much!
