Round Borosilicate Glass With Chamfer

Specifications

1. round borosilicate glass
2. high resistance to thermal shock
3. low coefficient of expasion
4. chamfer or round edge

round borosilicate glass



I. Application of borosilicate glass

1).  Household electrical appliance (panel for oven and fireplace, microwave tray etc.);

2).  Environmental engineering and chemical engineering (lining layer of repellence, autoclave of chemical reaction and safety spectacles);

3).  Lighting (spotlight and protective glass for jumbo power of floodlight);

4).  Power regeneration by solar energy (solar cell base plate);

5).  Fine instruments (optical filter);

6).  Semi-conductor technology (LCD disc, display glass);

7).  Iatrology and bio-engineering;

8).  Safety protection (bullet proof glass)



II. Specification of Product

1) Dimensions: 1150mm×1700mm 1150mm×850mm other formats upon request

2) Available thickness: 2mm--12mm, 20mm
3) Net sized glass of strengthening can be supplied as per the customers requirement;
4) Glass of small cut size is available according the requirement from customers.



III. Performance of the Product
1).  Mechanical Performance
Density  ρ              2.23±0.02g/cm3

2). Thermodynamic Performance
Thermal expansion coefficient           (0-300) 3.3±0.1×10-6K-1
Softening point        820±10
Strain point        516±10
Caloricity (20-100) 0.82KJ × (kg×K)-1
Thermal coefficient        1.2W×m×K-1
Thermal shock resistance 180K
Strengthening type 300K
Identical temperature difference 100K
Strengthening type 300 K
Maximum working temperature Short time(<10h): 500
 Long time(>10h): 450
3).  Chemical Performance
Water resistance          ISO719/DIN12111 HGB1/ISO720 HGA1
Acid resistance             ISO1776/DIN12116 1
Alkali resistance           ISO695/DIN52322 A2
4). Optical Property
Refractive index Nd: 1.47384
Transmittance spectrum curve

5). Electrical Property
Specific resistance lgρ  8.0Ω×cm at 250
Dielectric dissipation fraction tan σ (1 megacycle at 20): 38×10-4
Dielectric constant ε=4.7

The above mentioned specifications are in conformity with standard of ISO3585 after inspection and detection as well as examination by the Quality Supervision and Inspection Center of the National Light Industry for Glass Product and, Beijing Glass & Ceramic Quality Supervision and Inspection Center.



IV.  Means of Processing for Customers
 Cutting
 Round corner
 Round edge
 Surface fine polishing
 Hole drilling
 Coating
 Surface printing and sand blasting
 Thermal bending















Look forward to doing business with you!!!
