Specifications
Same configuration with CAMOGA CN420 seriesFEATURE
1. Indicate the splitting thickness by number and feed with stepless speed changing.
2. The automatic feed registration device dont need adjust cutting tool.
3. Automatically adjust the pressure pad clearance of cutting tool to make the splitting precision higher.
4. Freestanding duster of scurf and knife grinding dust.
5.Automatic stop system of leather material entangling.
6. Automatic detection system of electronic phase.
7. The single handle can adjust the knife grinding equipment and start the automatic control equipment.
8. The super fly wheel makes the operation of band knife more steady and exact.
9. The super long band knife of 3500mm is durable and economy, which reduce the cost.
10. The exact rail makes the movement of fly wheel more reliable and the replacement band knife more easy, quick and convenient.
11. Can split various leathers and freely adjust the pressure of splitting.
12. Appropriate working height can reduce the tire of operation.
13. The mechanical parts always lubricate.
Technique Parameter
Model | TW-420 |
Width of split(Max.) | 420mm |
Thickness of split(Max.) | 8mm |
Thickness of split(Min.)
| 0.15mm with top bar |
0.5mm with top feed roll | |
Feed speed | 1-20m/min |
Band-knife size | 3500*50*0.7mm |
Power of motor | 3.5kw |
Machine size | 1580*1050*1210mm |
Package size | 1760*1260*1410mm |
Net Weight | 635kg |
Gross Weight | 815kg |
