Top Brand 20KW Soundproof Diesel Generator Mobile Station Trailer With Wheels

Specifications

Trailer generator moble station with soundproof
1>K4100D engine ,copper alternator
2>Offer spare parts
3>One year after sales

  Top Brand 20KW Soundproof Diesel Generator Mobile Station Trailer With Wheels

Generators Diesel Standard Configurations
1	Standard High-level quality engine Ricardo series
2	Standard High-level quality alternator, Stanford, Brushless, 100% copper wires. Protection Grade: IP23, Insulation Class H.
3	No-maintenance start battery
4	After acidification under frame, High-level strong
5	Electric start, use key start
6	Standard control panel Spray-print or LCD show panel
7	Daily fuel tank
8	High-level shock absorber system
9	Ripple flexes exhaust pipe, exhaust siphons, flange, Muffler
10	40°C radiator as standard
11	Exhaust silencer
12	Charger motor for battery.
13	Standard export box
14	Manuals
15	Tools box





Generator Ratings

Standby Output(KW/KVA)	Prime Out(KW/KVA)	P.F	Phase	Wires	Size(mm)	Weight  (KG)
22/27.5	20/25	0.8	3	4	1600*600*1100	450

Diesel Engine Data

Engine Model	K4100D
Cylinder No.	4
Intake Method	Natural Aspiration
Engine Type	Inline, Direct injection, Four-stroke, water cooling
Displacement(L)	3.61
Bore*Stroke(mm)	100*115
Engine Max outout(kw/kva)	33/41.25
Fuel consumption(g/kw.h)	≤248
Start Method	DC 12V
Manufacture	Ricardo/Weifang

Alternator Data

Alternator Model	XN-20/Stanford
Alterantor Capacity	20kw/25kva
Voltage(V)	110/220 230/400
Speed	1500/1800
Excitation Method	Brush/Brushless
Power Factor	0.8
Frequency (HZ)	50/60

Our Engine Features





Diesel Gengine----Ricardo



Ricardo diesel generators, adopting diesel engines as power, which are manufactured by the company introducing British Ricardo technology, bear the features of compact structure, convenient operation, stable operation, low fuel consumption, low emission and low noise. Each performance indicator has reached National standard JB/T8981-1999, also meeting international standard IEC34-1. The product is widely used in numerous industries, including highways, telecommunications, hospitals, securities companies, high-rise buildings, public security, transportation systems, television station and etc.



Features of Ricardo diesel generator sets:



1. Ricardo diesel generators have good power performance, economic and sound reliability, emission reaching Euro II standard
2. Ricardo diesel generators adopt vertical four-cylinder, six-cylinder, water-cooled, four stroke, direct injection high-speed diesel engine.
3. Ricardo diesel generators have passed IS09001 quality system certification.







Huaquan provides a full line of brand new and high quality products.Each and every unit is strictly factory tested Warranty is according to our standard conditions:12 months or 1000 running hour’s ,subject to the earlier one .Service and parts are available from our factory.









 We specialized in producing diesel generators. We have exported to many countries and widely used in domestic.



 1. Exported countries: Nigeria, Indonesia, Malaysia, Philippine, North Korea, Ghana, Gabon, South Africa, Guinea, Russia, Iraq, Iran, Colombia, Burkina Faso, Liberia, Zambia, etc.

2. Domestic: Send to most of the cities in china, and get high praise from our clients.







  1.What's your power range of Generators?

Answer:  We can offer the range from 10kva~1000kva.

2.What's your delivery time?

Answer:  Generally,we can delivery in 7 days after we get the deposit.

3.What's your payment?

Answer:  We accept T/T ,and 30% as the deposit,the balance payment should be paid before shipping.

4.What's your warranty?

Answer:  All our products we offer on year warranty.

5.What's your MOQ?

Answer:We accept the MOQ  is 1 set.
