Multi-colored insulation sleeve,flexible water-proof pipe sleeve,flexible pvc pipe insulation sleeve
USD $0.01 - $10
/ Roll
100 Rolls(Min.Order)
- 2147483647 Roll / Rolls per Month
- Ningbo or Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | INFA | Model Number: | DRS |
| Type: | Other, tube, Insulation Sleeving | Material: | Other, Polyolefin |
Product Description
Function: 1. wire coat and insulation.
2. make the joint of terminal block and wire insulated.
3. divide the colors.
4. water-proof.
5. protection and insulation of insistors and electrical capacitors.
Standard color: black, white, rde, blue, yellow, green, brown, grey, orange and purple.
Item No. | Before Shrink | After Shrink | |||
| Package | |||||
| DIA.(mm) | Thickness(mm) | DIA.(mm) | Thickness(mm) | (Meter) | |
| DRS-1.0 | 1.0 | 0.2±0.05 | 0.85 | 0.4±0.05 | 200 |
| DRS-1.5 | 1.5 | 0.2±0.05 | 0.75 | 0.4±0.05 | 200 |
| DRS-2.0 | 2.0 | 0.25±0.05 | 1.00 | 0.45±0.1 | 200 |
| DRS-2.5 | 2.5 | 0.25±0.05 | 1.25 | 0.45±0.1 | 200 |
| DRS-3.0 | 3.0 | 0.25±0.05 | 1.50 | 0.45±0.1 | 200 |
| DRS-3.5 | 3.5 | 0.25±0.05 | 1.75 | 0.45±0.1 | 200 |
| DRS-4.0 | 4.0 | 0.25±0.05 | 2.00 | 0.45±0.1 | 100 |
| DRS-5.0 | 5.0 | 0.35±0.05 | 2.50 | 0.55±0.1 | 100 |
| DRS-6.0 | 6.0 | 0.35±0.05 | 3.00 | 0.55±0.1 | 100 |
| DRS-7.0 | 7.0 | 0.35±0.05 | 3.50 | 0.55±0.1 | 100 |
| DRS-8.0 | 8.0 | 0.35±0.05 | 4.00 | 0.55±0.1 | 100 |
| DRS-9.0 | 9.0 | 0.35±0.05 | 4.50 | 0.55±0.1 | 100 |
| DRS-10 | 10.0 | 0.35±0.05 | 5.00 | 0.60±0.1 | 100 |
| DRS-11 | 11.0 | 0.35±0.05 | 5.50 | 0.60±0.1 | 100 |
| DRS-12 | 12.0 | 0.35±0.1 | 6.00 | 0.70±0.1 | 100 |
| DRS-13 | 13.0 | 0.35±0.1 | 6.50 | 0.70±0.1 | 100 |
| DRS-14 | 14.0 | 0.35±0.1 | 7.00 | 0.70±0.1 | 100 |
| DRS-15 | 15.0 | 0.35±0.1 | 7.50 | 0.70±0.1 | 100 |
| DRS-16 | 16.0 | 0.35±0.1 | 8.00 | 0.70±0.1 | 100 |
| DRS-18 | 18.0 | 0.4±0.1 | 9.00 | 0.80±0.1 | 100 |
| DRS-20 | 20.0 | 0.5±0.1 | 10.00 | 0.90±0.1 | 50 |
| DRS-22 | 22.0 | 0.5±0.1 | 11.00 | 0.90±0.1 | 50 |
| DRS-25 | 25.0 | 0.5±0.1 | 12.50 | 0.90±0.1 | 50 |
| DRS-28 | 28.0 | 0.5±0.1 | 14.00 | 0.90±0.1 | 25 |
| DRS-30 | 30.0 | 0.5±0.1 | 15.00 | 1.00±0.2 | 25 |
| DRS-35 | 35.0 | 0.5±0.1 | 17.50 | 1.00±0.2 | 25 |
| DRS-40 | 40.0 | 0.5±0.1 | 20.00 | 1.00±0.2 | 25 |
| DRS-50 | 50.0 | 0.5±0.1 | 25.00 | 1.00±0.2 | 25 |
| DRS-60 | 60.0 | 0.6±0.1 | 30.00 | 1.20±0.2 | 25 |
| DRS-70 | 70.0 | 0.6±0.1 | 35.00 | 1.20±0.2 | 25 |
| DRS-80 | 80.0 | 0.6±0.1 | 40.00 | 1.20±0.2 | 25 |
| DRS-90 | 90.0 | 0.6±0.1 | 45.00 | 1.30±0.2 | 25 |
| DRS-100 | 100 | 0.7±0.1 | 50.00 | 1.30±0.2 | 25 |
| DRS-120 | 120 | 0.7±0.1 | 60.00 | 1.30±0.2 | 25 |
| DRS-150 | 150 | 0.8±0.1 | 75.00 | 1.60±0.2 | 25 |
...
