Home > Products > Grinding equipment > High Pressure Grinding Mill-Powder Mill YGM4121

High Pressure Grinding Mill-Powder Mill YGM4121

FOB Price

USD $10,000 - $100,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Shanghai
Payment Terms:T/T L/C D/P D/A

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Type:	Other, Powder Grinding Mill, Pulverizer	Application:	mining, GCC,CACO3,limestone,zeolite,dolomite,marble,barite and other stones
Motor Type:	AC Motor	Power(W):	75kw	Capacity(t/h):	10
Place of Origin:	Shanghai, China	Brand Name:	Dingbo Machinery	Model Number:	YGM4121
Certification:	ISO,CE	Warranty:	1Year	After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

The products should be processed to be rustproof and moisture proof before delivery. The small parts are packed into wooden crates; the big parts are wrapped by plastic sheeting.

Product Description

Specifications

Powder Mill
1.ISO9001:2000
2.Model: YGM4121
3.Capacity:10t/h

High Pressure Grinding Mill
The grinding processing materials can be grinding quartz, feldspar, calcite, talc, barite, fluorite, rare earths, marble, ceramic, aluminum bauxite, manganese ore, iron ore, copper ore, phosphate rock, red iron oxide, zircon sand, slag, cement clinker, activated carbon, dolomite, granite, garnet, iron oxide yellow, bean cake, chemical fertilizer , compound fertilizer, fly ash, bituminous coal, coke, lignite, Ling U.S. sand, chromium oxide green, gold,fluorspar, bentonite, , thermal insulation, materials in the 9.3 Mohs hardness below 6% moisture in a variety of non-explosive mineral materials processing.




High Pressure Grinding Mill Features
1.the Mill grinding roller pressure on the material under the action of the spring in the high-pressure increase 800 - 1200kg. 2.The Mill on the Mohs hardness of less than 9.3 processing of mineral materials can be crushed. 3.The Mill wide range of product particle size, particle size up to 0.613 mm the thickest (30 mesh) particle size of generally up to 0.033 mm (425 mesh), few materials can reach 0.013 mm the smallest (1,000 head).

YGM4121Mill Technical Parameters List
Item				High Pressure Grinding Mill
Model				YGM4121
Roller(pcs)				5
Diameter(mm)				Φ410
Roller Height(mm)				210
Inner Diameter(mm)				1280
Ring Height(mm)				210
Max Input Size(mm)				30
Discharging Size(mm)				0.613-0.033
Capacity(t/h)				2.8-10.5/h
Motor(kw)				75
Overall Dimension(mm)				9200×7250×9700

Company Profile

Shanghai Dingbo Heavy Industry Machinery Co., Ltd.

Shanghai Dingbo Heavy Industry Machinery Co., Ltd., located in Pudong New District of Shanghai, China, is a large enterprise specialized in the research, manufacture and sales of stone crushing and screening plants,coarse grinding mill and ultrafine powder mill equipments, covering an area of forty thousand square meters.

As one of the pioneer manufacturers, we have been engaged in crushers and micron grinding mills for over 20 years. And we still insist on the communication and cooperation with prestigious scientific research institutions to strengthen the ability in machinery design, production, maintenance, testing and reform. With several years' efforts, Dingbo now grows to be a first-class manufacturer of machineries with a complete advanced production system for superb equipment.

Our popular products include:
1) Stone crushers: jaw crushers, hammer crushers, impact crushers, roller crushers, cone crushers, fine stone crushers, vertical combination crushers, vertical impact crushers and so on.
2) Grinding mills: ball mills, cement mills, ceramic mills, raymond mills, micropowder mills and so on.
3) Ore beneficiation machines: magnetic separators, flotation machines, spiral chutes, spiral classifiers, shaking tables, mixed barrels, jiggers, centrifugal separators and so on.
4) Screens: vibrating screens, drum screens, rotary screens, linear screens and so on.
