•Typical applications include creating water fountains, pumping water for garden water features and conducting pond or aquarium water filtration and aeration.
•The solar water pump system for pond kit consists of a DC brushless water pump,a solar panel module and a backup battery.
•Solar energized, maintenace free, cost free and easy to install.
•No failure-prone carbon brush or shaft seal so that a robust and long service life could be expected.
•Battery back up, runs perfectly on overcast day and in the night.
•With a timer to enable the pump working intermittently when necessary.
•Ceramic shaft, runs steadily and quietly.
•Rohs and CE certified, safe and green.
•Designed and manufactured to have high power efficiency.
•Cost-effectiveness, competitive price.
Item No. | SPB20-501210 | ||||||||
Description | Solar brushless pump kit | ||||||||
Category | Solar pump kit | ||||||||
| |||||||||
Product Summary | |||||||||
Solar panel | Solar panel item | GSP20-36 | |||||||
Peak power | 20W | ||||||||
Peak power voltage | 17.28V | ||||||||
Peak power current | 1.157A | ||||||||
Pump | Pump item | BP501210 | |||||||
Maximum pump head | 3.2m (10.5ft) | ||||||||
Maximum flow rate | 1560L/H (412.1GPH) | ||||||||
Cable length | 5m (16.4ft) | ||||||||
nozzle item | NA03 | ||||||||
Battery back-up | Item No | SBB12-7 | |||||||
Extension cord length | 5m (16.4ft) | ||||||||
Battery type | Lead Acid | ||||||||
Battery capacity | 12V, 7Ah | ||||||||
Flow adjustable | no | ||||||||
Dry run protection | no | ||||||||
Master carton size | 54X37X27cm | ||||||||
Quantity per carton | 1pcs | ||||||||
Master carton G.W | 7.5kg | ||||||||
Quantity per 20 container | 512pcs | ||||||||
Quantity per 40 container | 1056pcs | ||||||||
Warranty | 3years | ||||||||
| |||||||||
Litres per hour - At various pumping heights (Head) | |||||||||
Operating | @ 0m | @0.5m | @0.75m | @1.0m | @1.5m | @2.0m | @2.5m | @3.0m | Max height |
12V | 980 | 550 | 300 | 0 |
|
|
|
| 1.0m |
18V | 1360 | 1070 | 840 | 755 | 420 | 60 | 0 |
| 2.1m |
24V | 1560 | 1480 | 1200 | 1190 | 930 | 690 | 430 | 50 | 3.2m |
| |||||||||
Pump Curve | |||||||||
| |||||||||
Overview | |||||||||
| |||||||||
