12 1/4" IADC137 Steel Tooth Tricone Bit/ Rock bit,casting,steel scrap price,goods from china

Specifications

competitive price with high quality
timely delivery
ISO$API
inspection company,likeSGS.VB
YOU RUN AT NO RISK.

1-Structural features

1.Cutting structure this type TCI tricone bits:

The durability of premium tungsten carbide insert is improved with new formulas and new techniques for insert bit.

2.Gauge structure this type TCI tricone bits:

Multiple gaugeprotection with gauge trimmers on the heel of cone, tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability and bearing life.

3.Bearing structure of this type TCI tricone bits:

High precision bearing with two thrust faces. Ball lock the cone. Hardfaced head bearing surface. Cone bearing inlaid with friction-reducing alloy and then silver-plated. Abrasion resistance and seizure resistance of the bearing are improved.

4.Seal and Lubrication of this type TCI tricone bits:

Premium O-ring, optimal seal compression and curved seal structure can enhance the seal performance. The pressure compensator system and advanced grease can greatly increase the lubricating reliability .

5.Product Application this type TCI tricone bits:

It can receive high WOB in the conventional drilling. It is suitable for various formations by matching cutting structure with different tooth shape, tooth density and tooth exposure height.



2-Specifications of TCI AND STEEL TOOTH BIT

• IADC	WOB (KN/mm)	RPM (r/min)	Applicable Formations
  114/116/117	0.3~0.75	180~60	Very soft formations with low compressive strength and high drillability, such as clay, mudstone, chalk, etc.
  124/126/127	0.3~0.85	180~60	Soft formations with low compressive strength and high drillability, such as mudstone, gypsum, salt, soft limestone, etc.
  134/135/136/137	0.3~0.95	150~60	Soft to medium formations with low compressive strength and high drillability, such as medium soft shale, hard gypsum, medium soft limestone, medium soft sandstone, soft formation with harder interbed, etc.
  214/215/216/217	0.35~0.95	150~60	Medium formations with high compress strength, such as medium soft shale, hard gypsum , medium soft limestone, medium soft sandstone, soft formation with harder interbed, etc.
  227	0.35~0.95	150~50	Medium hard formations with high compressive strength, such as abrasive shale, limestone, sandstone, dolomite, hard gypsum, marble,etc
  Note: The upper limits of WOB and RPM in above table should not be used simultaneously.

  IADC	WOB (KN/mm)	RPM (r/min)	Applicable Formations
  417/437/  447/415/435	0.35~0.9	150~70	Very soft formations with low compressive strength and high drillability, such as clay, mudstone, chalk, gypsum, salt, soft limestone, etc.
  517/527/515	0.35~1.0	140~60	Soft formations with low compressive strength and high drillability, such as mudstone, gypsum, salt, soft limestone, etc.
  537/547/535	0.45~1.0	120~50	Soft to medium formations with low compressive strength, such as medium, soft shale, medium soft limestone, medium soft sandstone, medium formation with harder and abrasive interbeds, etc.
  617/615	0.45~1.1	90~50	Medium hard formation with high compress strength, such as hard shale, limestone, sandstone, dolomite. etc
  637/635	0.5~1.2	80~40	Hard formations with high compressive strength, such as sandstone, limestone, dolomite ,hard gypsum, marble, etc.
  Note: The upper limits of WOB and RPM in above table should not be used simultaneously.

  3-Advantages:
• High-strength, high flexibility, high temperature and high wear resistance. 2. High-precision metal seal. 3. Locking roller ball, to adapt to high-speed. 4. The use of high strength high toughness carbide teeth, 5. Hours in the rotary cone bit with the impact, crushing and shearing the role of broken rock. 6. Cone bit to adapt to the soft, medium and hard of various strata. 7. Reasonable price and long working life.
•
•
• 4-INSPECTION
•
• 5-HOW TO PLACE THE ORDER

• Step:

  1. Firstly decide the design, material and color

  2. Decide the size in accordance with client's requirement and our recommendation

  3. We will give the best offer.

  4. Client's accept the offer and we send proforma invoice.

  5. Client transfers 30%-50% deposit and production begins

  6. After production, we will send ready products photo

  7. After client's confirmation, we will arrange shipment, and send copy shipping documents like B/L, commercial invoice and packing list

  8. Client transfer balance payment and we will send original documents by express or Telex Release

•  6-CONTACT PERSON:Alice di
•
•
