Ugee Graphic Tablet Digital Drawing Board 2048 levels

Specifications

Specifications
1. small tablet 2048 level,8x6inch
2. pass FCC,CE&ROHS certifications
3. professional factory of tablet

Graphic Drawing Tablet  8x6 inch

Technical Parameter



Brand	UGEE
Mode	M860
Pressure sensitivity	2048level
Active Area	8x6 inch
Report Rate	200 RPS
Resolution	4000 LPI
Reading Height	10mm
Accuracy	±0.01 inch
Hot Keys	Yes
Interface Support	USB
Pen	P51with AAA battery
Pen Holder	Yes
Color	Black
Dimension and Weight
Dimension Length	276.2mm
Dimension Width	251mm
Dimension Hight	10.3mm
Total Weight	536g
Accessories Included
Pen	P51
Pen Holder	Yes
Installation CD	Yes
Replacment Tips	8pcs
Tip Remove Tool	Yes
USB Cable	Yes (150cm)
User English Manual	Yes
Battery	No







Q. How can I get the update software?



A. You can download the new driver from our website---



   1. uninstall your old driver:Click[Start][All Programs][TABLET][Uninstall]



   2. Download the latest version of driver in the download section and save it into your hard disk



   3. Unzip the file in a folder on your hard disk(with Windows built-in unzip utility or a program like Winzip for instance).



   4. Double-click the Setup.exe in the foler where you unzippped the file.







Q. The tablet cannot work.How can I do?



A.  Pls follow steps as showing below:



  1.    Pls pull off the tablet’s USB plug from the computer.



  2.    Remove the Tablet driver form the system.



  3.    Re-connect the Tablet’sUSB to the computer.



       3.1 Check whether the tablet’s LED is blinking or not? If the LED unlighted, that means the hardware is fault.



       3.2 Test your wireless digital Pen on tablet working area, if it can work as a mouse, which means the hardware is OK.If it doesn’t work, pls change the battery with a new one.



       3.3 After changed a new battery for the pen, if it still not working, that means the hardware is fault.



  4.    You can download the latest version of driver directly from our website  ---



  5.    After installing the new version of driver, the system will require you to restart your computer.



  6.    After restart your computer, on bottom right of the screen, you can find the tablet icon within there.



       6.1 If you can’t find the tablet icon on the bottom right of the screen, it means the driver fail in startup.It might caused by an incompatible issue.



       6.2 Check form [My computer]→[Properties]→[Hardware]→[Device Manager], if there is an exdamation mark occurs,it means the installed driver of tablet is incompatible with the windows stystem.If you have this problem, pls contact us for more service.



  7.   By clicking the tablet icon on the bottom right of the screen, you can test the pressure sensitivity to see whether the pen pressure function works or not.
